Каталог запасных частей к технике: Hidromek HMK 200W. HYDRAULIC PUMP
H343000201
1
2
3
4
5
6
7
7
8
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
28
29
30
31
32
33
35
36
37
38
39
40
40
40
41
42
43
44
45
46
47
48
48
50
51
51
52
52
52
53
54
55
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| H343000201 | H343000201 | Hydraulic Pump | |
| H349010069 | H349010069 | F.-R. Swash Ass'y | |
| H349010068 | H349010068 | F. Roty Group, Lap. | |
| H349010067 | H349010067 | R. Roty Group, Lap. | |
| H349010066 | H349010066 | Seal KIT | |
| H349010065 | H349010065 | Ass'y Tilting Pin | |
| H349010064 | H349010064 | Ass'y, Check 2 | |
| H349010063 | H349010063 | Ass'y, Check 1 | |
| H349010062 | H349010062 | Ass'y, Swash Plate | |
| H349010061 | H349010061 | Ass'y Cylinder, L | |
| H349010060 | H349010060 | Ass'y Cylinder, R | |
| 1 | H349010001 | Pump,Gear | |
| 2 | H349010002 | Prop.Red.ValveAss'y | |
| 3 | H349010003 | Shaft, (F) | |
| 4 | H349010004 | Shaft, (R) | |
| 5 | H349010005 | Coupling | |
| 6 | H349010006 | Being, Roller | |
| 7 | H349010007 | Being, Needle | |
| 8 | H349010008 | Spacer | |
| 9 | BlockCylinder | Block, Cylinder | |
| 10 | H349010010 | Piston | |
| 11 | Shoe | Shoe | |
| 12 | H349010012 | Plate | |
| 13 | H349010013 | Bush, Spherical | |
| 14 | H349010014 | Spring | |
| 15 | H349010015 | Plate, Shoe | |
| 16 | Plate | Plate | |
| 17 | Bush | Bush | |
| 18 | Support | Support | |
| 19 | H349010019 | Cover | |
| 20 | H349010020 | Casing, Pump | |
| 21 | H349010021 | Block, Valve | |
| 22 | Plate | Plate | |
| 23 | Plate | Plate | |
| 24 | H349010024 | Screw | |
| 25 | H349010025 | Screw | |
| 26 | H349010026 | Plug | |
| 27 | H349010027 | Plug | |
| 28 | H349010028 | Plug | |
| 29 | Pin | Pin | |
| 30 | H3490100030 | Piston | |
| 31 | H3490100031 | Stoper | |
| 32 | H3490100032 | Stoper | |
| 33 | Seat | Seat | |
| 34 | Stoper | Stoper | |
| 35 | Stoper | Stoper | |
| 36 | Ball | Ball | |
| 37 | Pin | Pin | |
| 38 | O-Ring | O-Ring | |
| 39 | O-Ring | O-Ring | |
| 40 | O-Ring | O-Ring | |
| 41 | O-Ring | O-Ring | |
| 42 | O-Ring | O-Ring | |
| 43 | O-Ring | O-Ring | |
| 44 | O-Ring | O-Ring | |
| 45 | H349010045 | Seal | |
| 46 | Ring | Ring | |
| 47 | Ring | Ring | |
| 48 | H349010048 | Nut | |
| 49 | H349010049 | Nut | |
| 50 | H349010050 | Ring | |
| 51 | H349010051 | Pin, Valve Plate | |
| 52 | H349010052 | Pin, Spring | |
| 53 | H349010053 | Bolt | |
| 54 | H349010054 | Screw | |
| 55 | H349010055 | Screw | |
| 56 | Plate | Plate | |
| 57 | H349010057 | Pin |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
