Каталог запасных частей к технике: Hidromek HMK 102S ALPHA. HOSE HOLDER SET (TELESCOPIC ARM)

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
2
2
3
4
5
6
7
8
9
10
11
12
12
13
14
15
16
17
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
Позиция на иллюстрации Заводской номер детали Название детали
1 N015890914 BOLT
2 N030810015 Washer
3 N010232486 Bolt
4 N025910086 Nut
5 N072130017 HOSE HOLDER, RUBBER
6 81049012 BRACKET, HOSE HOLDER
7 81049004 HOSE HOLDER, RUBBER
8 N015890398 Bolt
9 81049021 PLATE, HOSE HOLDER
10 N072130201 HOSE HOLDER, RUBBER
11 N025910050 Nut
12 N015890398 Bolt
13 81049021 PLATE, HOSE HOLDER
14 N072130201 HOSE HOLDER, RUBBER
15 81049023 BRACKET, HOSE HOLDER
16 N072130211 HOSE HOLDER, RUBBER
17 N025910050 Nut
18 N010232078 Bolt
19 N030810014 Washer
20 01920365 SLING, HOSE
21 81049023 BRACKET, HOSE HOLDER
22 N072130211 HOSE HOLDER, RUBBER
23 N015890398 Bolt
24 N025910050 Nut
25 N010232186 Bolt
26 N030810014 Washer
27 N025910062 Nut
28 N010232078 Bolt
29 01990989 BRACKET
30 N010380674 BOLT
31 81049043 PLATE
32 81048111 RUBBER
33 N030020121 Washer
34 N025910086 Nut
35 81049044 PLATE
36 N010380410 Bolt
37 81048112 RUBBER
38 N010380410 Bolt
39 N030810014 Washer
40 81049045 Hose holder plate
41 N072130100 HOSE HOLDER, RUBBER
42 81049038 PLATE
43 N072130132 HOSE HOLDER, RUBBER
44 N010380446 Bolt
45 N030810014 Washer
46 81049041 PLATE
47 N072130122 HOSE HOLDER, RUBBER
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
