Каталог запасных частей к технике: Hidromek 102S MAESTRO. COUPLING (K4) A80001 -

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
S06/42335
S06/42335
10
40
50
60
70
80
90
90
100
110
120
130
130
130
130
130
130
130
130
130
130
150
150
150
150
150
150
150
150
150
160
170
170
180
180
190
190
Позиция на иллюстрации Заводской номер детали Название детали
S06/42335 S06/42335 Coupling compl
10 S06/43417 Coupling
40 S06/43282 Piston
50 S06/43304 O-ring
60 S06/43305 O-ring
70 S06/43382 Cup spring
80 S06/43198 Shim
90 S06/43215 Circlip
100 S06/43286 Inner clutch disc
110 S06/43287 Outer clutch disc
120 S06/43288 End shim
130 S06/43523 Snap ring
130 S06/43528 Snap ring
130 S06/43527 Snap ring
130 S06/43526 Snap ring
130 S06/43525 Snap ring
130 S06/43524 Snap ring
130 S06/43522 Snap ring
130 S06/43521 Snap ring
130 S06/43520 Snap ring
130 SNAPRING Snap ring
150 SELF-ALIGNINGBEARING Self-aligning bearing
150 S06/43138 Self-aligning bearing
150 S06/43192 Self-aligning bearing
160 S06/43418 Disc carrier
170 TAROLLERBEARING Ta roller bearing
170 S06/43309 Ta roller bearing
180 ROLLERBEARING Roller bearing
180 S06/43279 Roller bearing
190 S06/43280 R-ring
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
