WIFMS INTERFACE
WITOS
FIRE EXTINGUISHER
TГњV ITALY
TГњV
TГњV
MAINTENANCE KITS AND REPAIR KITS
2
2
4
5
5
6
7
8
8
12
13
14
20
Позиция на иллюстрации
Заводской номер детали
Название детали
2
2255841
WIRE HARNESS FMS
4
386197
BLADE-TYPE FUSE
5
2264087
CABLE HARNESS
6
339180
HEXAGON SCREW
7
2127020
HEXAGONAL NUT
8
2175172
LOCKING WASHER
12
380687
WIRE FASTENER
13
2262047
COUNTERPLUG
14
2286099
ELECTRONIC UNIT WITH HOUSING
20
2329674
INTERFACE
