10
11
12
13
13
14
14
14
16
18
19
21
22
23
97
150
170
285
440
441
441
442
442
443
444
451
451
455
455.01
470
471
472
473
474
Позиция на иллюстрации
Заводской номер детали
Название детали
10
2117179
WIRE HARNESS POTENTIOMETER
11
2079003
LEVER
12
2164759
THREADED ROD
13
200743
ANGLE JOINT
14
2127017
HEXAGONAL NUT
16
2158275
BOLT
18
2175172
LOCKING WASHER
19
2119339
HEXAGON SCREW
21
2042982
METAL PLATE
22
1237853
CHEESE-HEAD SCREW
23
274356
WASHER
97
2041579
MOUNTING CLIP
150
2158947
BELLOWS
170
2321456
CONNECTING LINK RIGHT
285
2024268
FILLISTER HEAD SCREW
440
2140366
SEAT PEDESTAL
441
314080
HEXAGON SCREW
442
314242
HALF-CLIP
443
2183199
SHIFTING SHAFT
444
2183211
TOP COVER
451
200751
ANGLE JOINT
455
2192187
DRIVE LEVER
455.01
2140477
DRIVE LEVER
470
2117340
CLAMPING PIECE
471
2117367
CLAMPING PIECE
472
367567
CHEESE-HEAD SCREW
473
239666
HEXAGONAL NUT
474
224820
SPRING-THRUST PIECE
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
Дополнительная информация
×
Название:
Номер:
Примечание:
