10
40
50
70
90
110
120
140
150
160
170
180
190
670
670
680
690
700
Позиция на иллюстрации
Заводской номер детали
Название детали
10
2059842
ROLLER DRUM
40
2078580
BEARING FLANGE
50
379727
O-RING SEAL
70
2057204
GEAR HUB MOTOR COMPL.
90
201928
O-RING SEAL
110
1285823
CHEESE-HEAD SCREW
120
2175178
LOCKING WASHER
140
1285823
CHEESE-HEAD SCREW
150
336009
CYLINDRICAL ROLLER BEARING
160
2059898
UNBALANCE SHAFT
170
837156
UNBALANCE VV/VO/VT
180
386022
CHEESE-HEAD SCREW
190
2128205
CIRCLIP
670
219487
SEALING RING
680
1259210
REDUCING PIECE
690
386880
LOCKING SCREW
700
237256
INSPECTION GLASS
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
