30
50
100
100
150
160
170
170
180
190
200
210
220
230
240
250
260
260
300
310
320
330
350
360
370
380
390
430
440
450
460
470
490
500
510
520
530
540
550
560
570
630
630
640
640
Позиция на иллюстрации
Заводской номер детали
Название детали
30
2059714
FLANGE
50
379727
O-RING SEAL
100
214701
CHEESE-HEAD SCREW
150
348732
CYLINDRICAL ROLLER BEARING
160
2059716
UNBALANCE SHAFT
170
844276
UNBALANCE VERSION,VV/VO/VT
170
844306
UNBALANCE VERSION,HV
180
386022
CHEESE-HEAD SCREW
190
2128203
CIRCLIP
200
2059713
FLANGE
210
381403
O-RING SEAL
220
250473
WASHER VERSION 3411
230
356158
CHEESE-HEAD SCREW
240
486930
RING
250
579734
SPLINE BUSH
260
217735
CIRCLIP
300
486892
CONE FLANGE
310
383341
O-RING SEAL
320
250473
WASHER VERSION 3411
330
356255
CHEESE-HEAD SCREW
350
383260
AXIAL FACE SEAL
360
288268
GROOVED BALL BEARING
370
477494
RING
380
370665
GROOVED BALL BEARING
390
486922
FLANGE
430
477486
LID
440
312886
CHEESE-HEAD SCREW
450
864277
DRIVER
460
293873
WASHER
470
2119451
HEXAGON SCREW
490
1490494
FLANGE
500
261297
O-RING SEAL
510
1464868
COVER SHEET
520
367575
CHEESE-HEAD SCREW
530
276332
LOCKING WASHER
540
213799
HEXAGON SCREW
550
397520
CONSTANT MOTOR COMPL.
560
276332
LOCKING WASHER
570
214469
CHEESE-HEAD SCREW
630
219487
SEALING RING
640
386880
LOCKING SCREW
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
Дополнительная информация
×
Название:
Номер:
Примечание:
