1
2
3
4
5
6
7
8
9
10
11
12
13
14
27
320
325
325
330
Позиция на иллюстрации
Заводской номер детали
Название детали
1
2202390
METAL PLATE
2
2203644
DECAL KIT
3
1200640
PIPE CLIP
4
325449
CHEESE-HEAD SCREW
5
2175169
LOCKING WASHER
6
2127017
HEXAGONAL NUT
7
1210076
CHEESE-HEAD SCREW
8
350389
WASHER
9
2029592
DISTANCE BUSH
10
2182793
HOLDER
11
2139203
CONNECTOR HOUSING
12
2035441
BLIND PLUG
13
380687
WIRE FASTENER
14
2036600
FILLISTER HEAD SCREW
27
2233660
HCQ-E-BOX HCQ
320
2182685
CABLE HARNESS
325
2174186
CABLE HARNESS
330
380687
WIRE FASTENER
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
