90
91
91
92
93
94
95
95
96
97
98
99
100
101
102
Позиция на иллюстрации
Заводской номер детали
Название детали
90
2138194
LEVER
91
2138208
METAL PLATE
92
2138182
DISTANCE PIECE
93
1212729
HEXAGON SCREW
94
2175172
LOCKING WASHER
95
367729
POTENTIOMETER
96
247588
CHEESE-HEAD SCREW
97
320854
SERRATED LOCK WASHER
98
2138183
HUB
99
271756
THREADED PIN
100
2138185
LID
101
245615
THREADED PIN
102
240885
COUNTERSUNK SCREW
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
