34
35
70
71
72
73
74
75
76
78
79
81
82
83
90
91
92
93
94
95
96
97
98
200
201
202
203
Позиция на иллюстрации
Заводской номер детали
Название детали
34
2103818
HOSE
35
2103819
HOSE
70
2079524
T-PIECE
71
2079525
T-PIECE
72
2074297
METAL PLATE
73
2071194
RUBBER SPOUT
74
2071193
RUBBER SPOUT
75
234605
CHEESE-HEAD SCREW
76
2175169
LOCKING WASHER
78
2149938
CAP
79
2149939
CAP
81
2036075
HALF-CLIP
82
387380
TOP COVER
83
1298402
CHEESE-HEAD SCREW
90
2095400
METAL PLATE
91
2036600
FILLISTER HEAD SCREW
92
314196
HALF-CLIP
93
314013
TOP COVER
94
314080
HEXAGON SCREW
95
313955
HALF-CLIP
96
314021
TOP COVER
97
2128332
HEXAGON SCREW
98
2053886
WIRE FASTENER
200
2103823
HOSE
201
2103822
HOSE
202
2115731
HOSE
203
2115732
HOSE
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
Дополнительная информация
×
Название:
Номер:
Примечание:
