Каталог запасных частей к технике: HAMM GRW 21. SOUND-INSULATION
1
2
2
5
5
7
8
12
17
18
19
25
26
27
28
29
35
36
37
38
40
41
42
44
45
73
76
77
78
80
81
82
85
86
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 1497227 | INSULATION PLATE | |
| 2 | 1497235 | INSULATION PLATE | |
| 5 | 416207 | INSULATION PLATE | |
| 7 | 416215 | INSULATION PLATE | |
| 8 | 416223 | INSULATION PLATE | |
| 12 | 1471376 | INSULATION PLATE | |
| 17 | 1523465 | INSULATION PLATE | |
| 18 | 434175 | INSULATION PLATE RIGHT | |
| 19 | 434183 | INSULATION PLATE LEFT | |
| 25 | 416274 | INSULATION PLATE | |
| 26 | 416312 | INSULATION PLATE | |
| 27 | 416304 | INSULATION PLATE | |
| 28 | 416290 | INSULATION PLATE | |
| 29 | 416282 | INSULATION PLATE | |
| 35 | 438472 | FOOT MAT | |
| 36 | 438480 | FOOT MAT | |
| 37 | 438499 | FOOT MAT | |
| 38 | 438502 | FOOT MAT | |
| 40 | 416371 | HOOD | |
| 41 | 213675 | HEXAGON SCREW | |
| 42 | 260983 | WASHER | |
| 44 | 213853 | HEXAGON SCREW | |
| 45 | 216607 | WASHER | |
| 73 | 1446436 | INSULATION PLATE | |
| 76 | 1446401 | SCRAPER BRUSH | |
| 77 | 1446428 | SCRAPER BRUSH | |
| 78 | 262285 | BOLT RIVET | |
| 80 | 1504932 | INSULATION PLATE | |
| 81 | 1504924 | INSULATION PLATE | |
| 82 | 1446215 | INSULATION PLATE | |
| 85 | 2096909 | INSULATION PLATE | |
| 86 | 2096910 | INSULATION PLATE |
