Позиция на иллюстрации
Заводской номер детали
Название детали
95
1266500
PUSH BUTTON
96
1266527
SWITCHING ELEMENT
97
833525
AUDIO SIGNAL TRANSMITTER
100
380296
IGNITION SWITCH
100.01
367125
KEY
101
335983
FOLDING LID
102
207705
BUILT-IN SOCKET
104
2068669
DASHBOARD
105
615487
SEALING TAPE
129
1269437
FRAME
130
1269445
FRAME
131
1263005
LID
132
1268686
SWITCH
133
1497774
ROCKER, TRACTION CONTROL
134
1267744
ROCKER, GEAR SHIFTING
135
1497804
ROCKER, VIBRATION
136
1267752
ROCKER, SIGNAL HORN
137
1267671
PUSHBUTTON
138
1268678
SWITCH
139
1497766
ROCKER, VIBR. MODE MAN.-AUTOM.
140
1262955
SWITCH
141
1264524
ALARM SYSTEM SWITCH
