Каталог запасных частей к технике: HAMM 3411. HEATING AND AIR CONDITIONING
1
1
2
3
4
4
5
5
6
6
7
8
9
10
11
11
12
12
13
13
14
15
16
16
16
16
16
17
18
19
20
20
21
22
23
24
24
25
25
26
26
27
28
29
30
31
32
33
34
35
36
37
38
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 2187097 | PLATE | |
| 2 | 2187098 | BRACKET | |
| 3 | 2187099 | BRACKET | |
| 4 | 2187101 | SCREW | |
| 5 | 2187108 | SPRING RING | |
| 6 | 1272659 | WASHER | |
| 7 | 2187111 | LID | |
| 8 | 2187116 | SCREW | |
| 9 | 216577 | WASHER | |
| 10 | 2187117 | SEALING | |
| 11 | 1272659 | WASHER | |
| 12 | 2187108 | SPRING RING | |
| 13 | 2187118 | SCREW | |
| 14 | 2187119 | SEALING | |
| 15 | 2171288 | COVERING PART | |
| 16 | 2187000 | RIVET | |
| 17 | 2187124 | WASHER | |
| 18 | 216577 | WASHER | |
| 19 | 2187120 | SCREW | |
| 20 | 2187121 | SCREW | |
| 21 | 2187122 | SEALING | |
| 22 | 2187123 | SEALING | |
| 23 | 2171286 | COVERING PART | |
| 24 | 2187121 | SCREW | |
| 25 | 2186993 | WASHER | |
| 26 | 2187124 | WASHER | |
| 27 | 2187126 | METAL PLATE | |
| 28 | 2187000 | RIVET | |
| 29 | 2187127 | SCREW | |
| 30 | 216577 | WASHER | |
| 31 | 2187124 | WASHER | |
| 32 | 2171290 | COVERING PART | |
| 33 | 2187129 | PLATE | |
| 34 | 2187132 | CLIP NUT | |
| 35 | 2043994 | RIVET | |
| 36 | 2187133 | WASHER | |
| 37 | 2187135 | WASHER | |
| 38 | 2187139 | SCREW |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
