1
3
9
11
19
21
23
25
51
53
54
60
66
73
74
Позиция на иллюстрации
Заводской номер детали
Название детали
1
1506986
FUSE BOX
3
892041
CABLE HARNESS
9
1293001
FUSE
11
1286919
FUSE
19
892343
CABLE HARNESS
21
1506099
METAL PLATE
23
276332
LOCKING WASHER
25
1209302
SAFETY NUT
51
1513834
HOLDER
53
392480
CHEESE-HEAD SCREW
54
216569
WASHER
60
1289829
RELAY
66
880604
HARNESS
73
2127017
HEXAGONAL NUT
74
320862
SERRATED LOCK WASHER
