Каталог запасных частей к технике: HAMM 3410. HEATING AND AIR CONDITIONING STANDARD
2
3
3
4
4
10
10
11
11
15
16
20
21
22
23
65
66
70
75
76
77
85
86
87
88
89
90
90
95
96
97
100
101
102
103
104
105
106
140
141
142
145
146
170
200
201
202
203
210
215.02
215.02
215.03
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 2 | 2179327 | COVERING PART COMPL. | |
| 3 | 232513 | FILLISTER HEAD SCREW | |
| 4 | 274356 | WASHER | |
| 10 | 385719 | ROUND NOZZLE | |
| 11 | 384771 | SHEET METAL SCREW | |
| 15 | 1263153 | DIFFUSER | |
| 16 | 384771 | SHEET METAL SCREW | |
| 20 | 1261150 | CONTROL MODULE | |
| 21 | 232513 | FILLISTER HEAD SCREW | |
| 22 | 1263145 | BOWDEN CABLE | |
| 23 | 2160758 | HOSE | |
| 65 | 1519050 | V-BELT PULLEY | |
| 66 | 214507 | CHEESE-HEAD SCREW | |
| 70 | 2467891 | V-BELT | |
| 75 | 1519182 | METAL PLATE | |
| 76 | 213888 | HEXAGON SCREW | |
| 77 | 345490 | WASHER | |
| 85 | 1220810 | EYE BOLT | |
| 86 | 1209787 | HEXAGON SCREW | |
| 87 | 388220 | SAFETY NUT | |
| 88 | 216607 | WASHER | |
| 89 | 1220829 | BUSHING | |
| 90 | 1270850 | COMPRESSOR | |
| 90 | 2071195 | COMPRESSOR | |
| 95 | 212822 | HEXAGON SCREW | |
| 96 | 388220 | SAFETY NUT | |
| 97 | 216607 | WASHER | |
| 100 | 1446835 | GUIDANCE | |
| 101 | 2257348 | DISTANCE BUSH | |
| 102 | 1209760 | HEXAGON SCREW | |
| 103 | 388220 | SAFETY NUT | |
| 104 | 216607 | WASHER | |
| 105 | 2127024 | HEXAGONAL NUT | |
| 106 | 216615 | WASHER | |
| 140 | 213667 | HEXAGON SCREW | |
| 141 | 216577 | WASHER | |
| 142 | 1502239 | CONDENSER | |
| 145 | 614022 | FOAM RUBBER PROFILE | |
| 146 | 1269909 | HOSE FITTING | |
| 170 | 1519999 | HOSE | |
| 200 | 1207563 | PIPE CLIP | |
| 201 | 339180 | HEXAGON SCREW | |
| 202 | 1209302 | SAFETY NUT | |
| 203 | 216593 | WASHER | |
| 210 | 1265873 | CABLE SUPPORT SLEEVE | |
| 215.02 | 2022493 | O-RING SEAL NW8 | |
| 215.03 | 2023822 | O-RING SEAL NW10 |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
