Каталог запасных частей к технике: Foton TL254 (TL1A254-001K). KM385BT-1F-1 CYLINDER BLOCK

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
7
10
12
14
17
18
19
22
22
23
24
27
27
28
29
29
30
33
34
35
36
37
39
40
41
42
43
Позиция на иллюстрации Заводской номер детали Название детали
1 KM385T-01029 BRACKET
7 L375-01006 WATER PUMP REAR COVER GASKET
10 KM385TE-01111 BLOCK
12 L375-01007 GASKET
14 D495QB-01024 PLUG PIECE
17 4L22BT-01021 IDLE BOLT
18 L375-01104 MAIN OIL LINE PLUG
19 l375-01106 LOCATING SLEEVE OF MAIN BEARING COVER
22 KM485QB-01112 MAIN BEARING COVER
22 KM485QB-01112 MAIN BEARING COVER
23 L375-01110 MAIN BEARING COVER BOLT WASHER
24 L375-01111 BOLT
27 KM485QB-01113 REAR MAIN BEARING COVER
28 D495QB-03109 PLUG PIECE
29 L375-01027 OIL FILTER GASKET
29 L375-01027 OIL FILTER GASKET
30 KM385T-01027 OIL FILTER WASHER BLOCK
33 KM385T-01035 CONNECTOR
34 L375-12500 ENGINE OIL PRESSURE SENSOR
35 D495QB-01014 BOWL PLUG
36 L375-01105-1 TAPER PLUG
37 D495QB-01024 PLUG PIECE
39 KM385TA-03302 EPAIV BRAND MARK PLATE
40 4L22BT-01600 DRAIN SWITCH
41 195-13007 WASHER
42 L375-01320-1 OIL DIPSTICK PIPE WELDMENT
43 KM385T-01310 OIL DIPSTICK PARTS
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
