Каталог запасных частей к технике: Foton TB454-Q161Y20K. FT300.39.001 FINAL TRANSMISSION ASSEMBLY-2

Тип техники

Марка

Модель

Схема

1

2

3

4

5

6

7

8

9

9

10

11

12

13

14

14

15

16

17

18

19

20

21

21

22

23

24

25

26

26

27

28

28

29

Позиция на иллюстрации	Заводской номер детали		Название детали
1	GBT6176-M16X1.5-LH-10-A3L		Hexagon nut, type-2
2	FT300.39.137		Washer
3	FT300.39.118		Driving shaft
4	FT300.39.135		Rear hub bolt
5	GBT5783-M12X30-8.8-A3L		Bolt
6	GBT93-12-AOP		Washer
7	FT300.39.116		Seat for oil sealing
8	GBT3452.1-115X3.55G		O-seal ring
9	GBT9877.1-FB70X95X10D		O ring
10	GBT276-6212		Ball bearing
11	FT300.39.114		Case of driving shaft, right
12	GBT276-6211		Bearing
13	FT300.39.113		Spacer sleeve
14	FT300.39.121		Adjusting shim
14	FT300.39.121		Adjusting shim
15	FT300.39.122		Adjusting shim
16	FT300.39.123		Adjusting shim
17	FT300.39.104		Planetary frame
18	FT300.39.111		Rest
19	FT300.39.112		Lock bolt of driving shaft
20	FT300.39.110		Lock plate of driving shaft
21	FT300.39.102		Half shaft, right
21	FT300.39.102		Half shaft, right
22	FT300.39.107		Ring gear
23	GBT879.1-5X24		Pin
24	GBT879.1-8X24		Pin
25	FT300.39.106		Shaft of planetary wheel
26	FT300.39.109		Outer spacer sleeve
27	FT300.39.103		Planetary wheel
28	GBT309-P5X23.8-G2		Needle
29	FT300.39.105		Inner spacer sleeve

Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
