Каталог запасных частей к технике: Foton FL958G. 9F850-76A000000B0 WORKING IMPLEMENT ACCESSORY

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
1
1
1
10
10
11
11
11
11
11
11
11
11
12
12
13
13
13
14
15
16
16
17
18
19
19
19
20
20
20
21
21
22
23
24
25
25
25
25
25
26
27
28
3
3
3
3
4
4
4
4
4
4
4
5
6
6
6
6
6
6
6
7
7
8
8
8
9
9
Позиция на иллюстрации Заводской номер детали Название детали
1 9F850-76A000001A0 Bolt
10 GBT16674.1-M16X35-8.8-A3L Bolt
11 9F850-76A030000A0 Pull rod seal
12 9F850-76A000004A1 Shaft sleeve of pulling rod
13 9F850-76A000005A0 Seal rubber ring
13 9F550-76A000006A0 Seal rubber ring
14 9F850-76A000006A1 Rocker shaft sleeve
15 9F850-76A040000A0 Rocker middle pin
16 9F850-76A050000A0 Rocker hole seal
17 9F850-76A000007A1 Boom middle shaft sleeve
18 9F850-76A070000A0 Rocker rear pin
19 9F850-76A000008A1 Adjusting washer 2
19 9F850-76A000008A0 Adjusting gasket 1
19 9F850-76A000005B0 Adjusting gasket
20 9F850-76A000009A0 Adjusting gasket 2
20 9F850-76A000009A1 Adjusting washer
20 9G661-76A000009A1 Adjusting washer
21 9F850-76A000010A0 Boom rear shaft sleeve
22 9F850-76A080000A0 Left lower shaft pin of bucket
23 9F850-76A090000A0 Rocker front pin
24 9F850-76A100000A0 Upper shaft pin of bucket
24.1 9F850-76A100000B0 Upper shaft pin of bucket
25 9F850-76A000012A0 Adjusting washer
25 9F850-76A000012A1 Adjusting washer
26 9F850-76A010000B0 Small chamber pin shaft assembly of
27 GBT5783-M18X40-8.8-A9L Bolt
28 GBT97.1-18-A3L Washer
3 GBT96.1-16-A3L Washer
4 JBT7940.1-M10X1 Straight pressure filling oil cup
5 9F850-76A010000A0 Right lower shaft pin, bucket
6 9F850-76A020000A0 Boom front hole seal
7 9F850-76A000002A0 Boom front shaft sleeve
8 9F850-76A000003B0 Seal rubber ring
9 9F850-76A000011A0 Retainer plate
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
