Каталог запасных частей к технике: Foton FL936F (FL936FH4C1B2X1A105). 9D650-76A000000B0 Work implement attachments
1
1
1
1
1
1
1
2
3
3
3
4
4
4
4
5
5
7
7
7
7
8
8
8
8
8
8
8
8
9
9
9
9
10
11
11
13
13
14
15
15
16
17
18
18
19
20
20
21
22
23
24
25
26
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | JBT7940.1-M10xl | Press filling oil cup | |
| 2 | 9D650-76A010000A0 | Bucket right pin shaft | |
| 3 | 9D650-76A000001A1 | Adjusting gasket | |
| 4 | 9D650-76A000002B0 | Adjusting gasket | |
| 5 | GBT16674.1-M16x35-8.8-A2L | Hex flange bolt | |
| 7 | GBT96.1-16-A0P | Big washer | |
| 8 | 9D650-76A020000A0 | Seal ring | |
| 9 | 9D650-76A000003A0 | Shaft bush | |
| 10 | 9D650-76A030000A0 | Rocker arm upper pin shaft | |
| 11 | 9F850-76A000001A0 | Bolt | |
| 13 | 9D650-76A040000A0 | Seal ring | |
| 14 | 9D650-76A000004A1 | Sleeve | |
| 15 | 9D650-76A060000A0 | Seal ring | |
| 16 | 9D650-76A000005A1 | Rocker arm pin shaft | |
| 17 | 9D650-76A070000A0 | Rocker arm middle pin shaft | |
| 18 | 9D650-76A000006A0 | Adjusting gasket | |
| 19 | 9D650-76A000007A0 | Adjusting gasket | |
| 20 | 9D650-76A000008A0 | Lifting arm rear shaft bush | |
| 21 | 9D650-76A080000A0 | Bucket left pin shaft | |
| 22 | 9D650-76A090000A0 | Pull rod front shaft pin | |
| 23 | 9D650-76A100000А0 | Rocker arm lower shaft pin | |
| 24 | 9D650-76A110000B0 | Lifting arm cylinder shaft pin | |
| 25 | GBT5789-M20x40-10.9-A2L | Hex flange bolt | |
| 26 | GBT96.1-20-A0P | Big washer |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
