Каталог запасных частей к технике: Foton FL936F (FL936FH4C1B2X1A105). 9D650-58B000000A0 Hydraulic oil tank
1
2
3
4
4
4
5
6
7
8
9
9
9
9
10
11
12
13
14
15
16
16
23
23
24
24
24
25
25
26
26
27
27
27
28
28
29
30
31
32
33
34
35
36
37
38
39
40
40
41
41
42
42
42
43
44
45
46
47
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 9F850-58A020000A1 | Oil level gauge | |
| 2 | 9D650-58A010000B0 | Hydraulic oil tank | |
| 3 | GBT5782-M12xl00-8.8-A2L | Hex bolt | |
| 4 | GBT93-12-A0P | Spring washer | |
| 5 | 9D650-58A020000B0 | Oil suction pipe assembly | |
| 6 | ISO3601-56.74x3.53-70 | 0-ring | |
| 7 | 9F850-58A040000A0 | Air filter | |
| 8 | GBT5783-M8x20-8.8-A2L | Hex bolt | |
| 9 | GBT93-8-A0P | Washer | |
| 10 | ISO3601-158.34x3.53-70 | 0-ring | |
| 11 | 9D650-58A030000A0 | Oil return filter cartridge | |
| 12 | 9F850-59A190000А0 | Pressure measuring joint M14x1.5ED | |
| 13 | 9D650-58A040000B0 | Oil return steel pipe assembly | |
| 14 | ISO3601-47.22x3.53-70 | 0-ring | |
| 15 | GBT5782-M12x90-8.8-A2L | Hex bolt | |
| 16 | ISO3601-132.94x3.53-70 | 0-ring | |
| 23 | GBT5783-M8xl6-8.8-A2L | Hex bolt | |
| 24 | GBT97.1-8-A0P | Washer | |
| 25 | GBT5783-M16x60-8.8-A3L | Hex bolt | |
| 26 | 9D650-58A000005A0 | Washer | |
| 27 | GBT93-16-A0P | Spring washer | |
| 28 | GBT6170-M16-8-A3L | Type 1 hexagon nut | |
| 29 | 9D650-58A000003A0 | Bending plate | |
| 30 | 9D650-58A000004A0 | U-bolt | |
| 31 | GBT6170-M8-8-A2L | I-type hexagon nut | |
| 32 | 9D652-58A000002A0 | U-bolt | |
| 33 | GBT97.1-12-A0P | Washer | |
| 34 | GBT6170-M12-8-A3L | Nut | |
| 35 | GBT5783-M16x30-8.8-A3L | Hex bolt | |
| 36 | 9D652-58A000001A0 | Bending plate | |
| 37 | 9D550-58A000001B0 | Oil discharge connector | |
| 38 | 9D550-58A000002B0 | Rubbercap | |
| 39 | 9D550-58A000003B0 | Label | |
| 40 | 9D650-58A010001B0 | Flange cover | |
| 41 | GBT5783-M10x20-8.8-A3L | Hex bolt | |
| 42 | GBT93-10-A0P | Washer | |
| 43 | 9D650-58A010200A0 | Filter cartridge bracket | |
| 44 | 9D650-58A010002A0 | Spring | |
| 45 | GBT5783-M10x25-8.8-A3L | Hex bolt | |
| 46 | 9D550-58A010300C0 | Oil drainage ball valve | |
| 47 | 9D650-58B010100B0 | Tank body |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
