Каталог запасных частей к технике: DYNAPAC Dynapac PL2000S. 500-07140 Drive

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
1
2
2
3
3
3
3
4
4
4
5
5
5
6
6
6
6
7
7
8
8
8
9
9
10
11
11
12
12
12
12
13
13
13
13
13
13
14
14
14
14
14
14
15
15
16
16
17
17
18
18
18
18
18
19
19
19
19
20
20
20
20
20
20
21
21
21
21
21
21
21
22
22
22
23
23
24
24
25
25
26
26
27
27
27
27
28
28
28
29
29
29
29
29
29
29
29
29
29
30
30
31
31
33
33
34
34
34.01
34.01
34.02
34.02
35
35
36
36
37
37
38
38
39
39
39
40
40
41
41
42
42
43
44
44
44
44
44
44
44
44
45
45
45
45
45
45
45
45
46
46
46
46
46
46
46
46
46
46
46
46
46
46
46
46
47
47
47
47
47
47
47
47
48
48
48
48
48
48
48
48
48
48
48
48
48
48
49
49
49
50
50
51
51
52
52
53
53
54
54
54
54
54
54
54
55
55
55
55
55
55
55
55
56
56
56
56
57
57
58
58
59
59
59
59
59
59
59
60
60
61
61
62
62
63
63
63
63
64
64
65
65
66
66
66
67
67
68
68
69
69
70
70
70
70
70
70
71
71
71
71
72
72
72
72
73
73
74
74
75
75
76
76
77
77
77
77
78
78
78
78
79
79
80
80
81
81
82
82
83
83
84
84
85
85
86
86
87
88
88
88
89
89
90
90
90
92
92
93
93
94
94
94
94
95
95
95
95
96
97
98
98
98
98
98
98
Позиция на иллюстрации Заводской номер детали Название детали
500070145 500070145 Drive
1 960872807 Hose
2 961935211 Straight double-ended union
3 960886625 Hose
4 930211285 Flange half
5 930211288 Flange half
6 928791 Cylinder screw
7 500070160 Pipeline
8 937932443 Cylinder screw
9 961154121 Male connector for swivel nut
10 961102022 Nut
11 961102072 Cutting ring
12 961935121 Straight double-ended union
13 961102021 Nut
14 961102071 Cutting ring
15 961935228 Straight double-ended union
16 960855781 Hose
17 961982612 T-Reducer screwing
18 961102009 Nut
19 961102059 Cutting ring
20 961102008 Union nut
21 961102058 Cutting ring
22 961982625 Reduction union
23 969181009 Straight screwing
24 961935109 Straight screwing
25 500070151 Pipeline
26 961935104 Straight double-ended union
27 963173203 Hydr. block
28 961935207 Straight double-ended union
29 961935209 Stud
30 500070152 Pipeline
31 960851060 Hose
32 961903022 Straight coupling
33 969181008 1ntermediate stud
34 963155700 Handpump
34.01 963155704 Way valve
34.02 960644917 Magnet
35 500070176 Pipeline
36 500070177 Pipeline
37 500070178 Pipeline
38 500070179 Pipeline
39 500070156 Pipeline
40 500070157 Pipeline
41 500070158 Pipeline
42 500070159 Pipeline
43 930296453 Ball valve
44 960875290 Hose
45 960876398 Hose
46 930211260 Flange half
47 961934201 Straight double-ended union
48 508053 Screw
49 961935106 Stud
50 500070161 Pipeline
51 500070162 Pipeline
52 500070163 Pipeline
53 500070164 Pipeline
54 961102006 Union nut
55 960823473 Hose
56 960855277 Hose
57 960854501 Hose
58 960854502 Hose
59 961102056 Cutting ring
60 960892581 Hose
61 500070165 Pipeline
62 500070166 Pipeline
63 961982615 Reduction union
64 500070168 Pipeline
65 500070167 Pipeline
66 961904006 Union elbow both ports
67 961904011 Union elbow both ports
68 961904008 Union elbow both ports
69 961903006 Stud
70 961935206 Straight screwing
71 960823251 Hose
72 961982602 Reduction screwing
73 500070170 Pipeline
74 500070171 Pipeline
75 961905008 Union tee
76 500070169 Pipeline
77 963173202 Hydr. block
78 960823603 Hose
79 960881910 Hose
80 500070172 Pipeline
81 500070173 Pipeline
82 500070209 Pipeline
83 500070210 Pipeline
84 500070211 Pipeline
85 500070212 Pipeline
86 500070213 Pipeline
87 961121020 Reduction screwing
88 961102011 Union nut
89 961102061 Cutting ring
90 961905011 Equal-tee
92 500070253 Pipeline
93 500070254 Pipeline
94 961903022 Straight coupling
95 961134125 Straight double-ended union
96 932323729 O-ring
97 932323744 O-ring
98 932323203 O-ring
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
