Каталог запасных частей к технике: DYNAPAC Dynapac PL2000S. 500-03150 Conveyor
/19.gif)
1
2
3
3
3
3
4
4
4
5
5
5
6
6
6
6
7
8
9
9
10
10
11
12
13
13
14
14
14
14
14
14
15
16
17
18
19
20
21
22
23
24
25
26
30
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | Conveyor | Conveyor | |
| 2 | Roller | Roller | |
| 3 | 930211416 | Upper belt pulley | |
| 4 | 930211418 | Upper belt pulley | |
| 5 | 930211421 | Lower belt pulley | |
| 6 | 930211422 | Side guide roller | |
| 7 | Hydraulic | Hydraulic, front flap | |
| 8 | 930211426 | Converyor belt | |
| 9 | 930211428 | Side sealing rubber | |
| 10 | 930211429 | Bearing | |
| 11 | 930211430 | Tension bearing plate | |
| 12 | 930211433 | Tension bearing plate motor side | |
| 13 | Screw | Screw | |
| 14 | Hex.Nut | Hex. nut | |
| 15 | 930211438 | Rubber guide, behind top | |
| 16 | 930211439 | Rubber guide, behind down | |
| 17 | 930404309 | Repair kit for drum | |
| 18 | 930118513 | Funnel | |
| 19 | 930101651 | Covering | |
| 20 | 930101652 | Covering | |
| 21 | 930101653 | Covering | |
| 22 | 930101654 | Covering | |
| 23 | 930101655 | Covering | |
| 24 | 930101656 | Covering | |
| 25 | 930101657 | Covering | |
| 26 | 930101658 | Covering | |
| 27 | 930101659 | Covering | |
| 30 | 966058505 | Hydraulic motor | |
| 30.01 | 966534203 | Sealing kit |
