Каталог запасных частей к технике: DYNAPAC Dynapac PL2000S. 500-04110 Steering, compl.

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
4
5
6
7
8
9
10
13
14
15
16
17
17
18
19
19
20
21
21
22
22
23
23
25
25
26
26
27
27
27
27
28
29
30
31
32
33
34
35
36
37
37
38
38
40
40
41
42
43
44
45
46
47
48
49
50
51
52
53
55
56
57
59
60
61
62
63
64
65
66
67
68
Позиция на иллюстрации Заводской номер детали Название детали
500040000 500040000 Steering
932785703 932785703 Sealing kit
500-05110 500-05110 Track group
Sensor Sensor Sonic sensor conveyor
932785697 932785697 Sealing kit
932785703 932785703 Sealing kit
932785697 932785697 Sealing kit
1 500040100 Guide legg 1 compl.
2 508005 Screw
3 49900161 Screw retention
4 508028 Cylinder screw
5 935112540 Hinge bearing
6 931810060 Circlip
7 935512155 Grease nipple
8 500040101 Track console, compl.
9 938111943 Hex. screw
10 936900029 Spring washer
13 500040110 Feather key
14 937939494 Screw
15 939940040 Feather disc
16 937932604 Screw
17 965172902 Cylinder with sensor
18 500040113 Crosstie, compl.
19 500040106 Fork head LH-threaded
20 500040116 Rod, front
21 500040115 Fork head RH-threaded
22 937181239 Hex. nut
23 937182239 Hex. nut left threaded
24 500040104 Guide legg 11 compl.
25 965172903 Cylinder
26 500040117 Вolt
27 936002527 Circlip ring
28 938590030 Disc
29 500040125 Bolt for steering
30 500028 Screw
31 500040118 Crosstie, compl.
32 500040119 Rod, rear
33 500040127 Telescopic tube outside
34 500040128 Teleskopic tube, innerside
35 500040129 Guide
36 500040130 Support lever
37 500040131 Chain holder
38 939130012 Washer
40 938481012 Safety nut
41 938111728 Hex. screw
42 500082 Screw M16x70
43 500040126 Angle
44 570006 Nut
45 937032601 Screw
46 939130014 Washer
47 500193 Screw
48 500040147 1ndicator
49 500040139 Support
50 500040141 Support rod
51 990020218 Bolt
52 500040146 Angle
53 500040148 Support holder
55 500197 Hex. screw
56 939130014 Washer
57 938780018 Hex. nut
59 500163 Screw M12x16
60 938150976 Hex. screw
61 936790702 Split pin
62 500040140 Support plate
63 500037 Hex. screw
64 936905020 Spring washer
65 600009 Washer
66 930240607 Half of support
67 932701291 Scraper
68 660913 Repair set for steering
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
