Каталог запасных частей к технике: DYNAPAC Dynapac PL2000LS. 951058552 Split gear boх Stiebel
/39.gif)
1
2
3
4
4
5
5
6
7
7
8
9
9
10
11
12
13
14
15
16
16
18
18
18
18
18
19
19
20
21
22
23
23
23
23
23
23
23
24
24
24
27
28
28
28
29
30
31
32
33
34
35
36
40
41
42
43
44
45
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 951058552 | 951058552 | Split gear boх | |
| 1 | 951025150 | Housing cover | |
| 2 | 951025151 | Housing | |
| 3 | 951040760 | Bearing flange | |
| 4 | 951073084 | Spur wheel | |
| 5 | 951073085 | Spur wheel | |
| 6 | 951073086 | Spur wheel | |
| 7 | 951088841 | Shaft | |
| 8 | 951022253 | Flanged shaft | |
| 9 | 951029668 | Profile shaft | |
| 10 | 951042020 | Track ring | |
| 11 | 951042021 | Track ring | |
| 12 | 951037221 | Coupling piece | |
| 13 | 951037222 | Coupling piece | |
| 14 | 951037223 | Coupling piece | |
| 15 | 951052855 | Dipstick | |
| 16 | 111196 | Roller bearing | |
| 18 | 111104 | Roller bearing | |
| 19 | 935004902 | Roller bearing | |
| 20 | 951062515 | Radial seal | |
| 21 | 951062516 | Radial seal | |
| 22 | 932211845 | O-ring | |
| 23 | 936004849 | Circlip | |
| 24 | 936002659 | Circlip | |
| 27 | 932101272 | Compensating washer | |
| 28 | 931706748 | Feather key | |
| 29 | 49900088 | Screw | |
| 30 | 936717711 | Plain pin | |
| 31 | 937914010 | Plug screw | |
| 32 | 951017041 | Vent valve | |
| 33 | 951036570 | Swivel nut elbow | |
| 34 | 961084050 | Extension | |
| 35 | 932702481 | Sealing washer | |
| 36 | 932702498 | Sealing washer | |
| 40 | 951095934 | Cylinder roller bearing | |
| 41 | 500193 | Screw | |
| 42 | 951089579 | Angle | |
| 43 | 937864006 | Plug screw | |
| 44 | 951036571 | Swivel nut elbow | |
| 45 | 956921603 | Gear oil |
