Каталог запасных частей к технике: DYNAPAC Dynapac PL2000LS. 504-05150 Track group
/35.gif)
1
3
4
5
6
7
8
9
10
11
12
13
14
16
17
18
19
20
22
23
24
25
25
28
29
30
33
34
35
36
37
38
39
40
41
41
43
46
48
49
50
51
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 966534235 | 966534235 | Seal kit | |
| 967610534 | 967610534 | Magnet | |
| 1 | 952761573 | Side cover, left | |
| 2 | 952761574 | Side cover, right | |
| 3 | 952606156 | Drive wheel | |
| 4 | 938170872 | Hex. screw | |
| 5 | 939010410 | Washer | |
| 6 | 500050300 | Track drive, compl. | |
| 7 | 951020924 | Drive gear box | |
| 8 | 966025365 | Adjust. motor | |
| 9 | 938130869 | Screw | |
| 10 | 939010410 | Washer | |
| 11 | 49900217 | Screw | |
| 12 | 939010413 | Disc | |
| 13 | 951053015 | O-ring | |
| 14 | 978033008 | Puls pick-up probe | |
| 16 | 952692001 | Chain with bottom plate | |
| 17 | 952692002 | Chain without bottom plate | |
| 18 | 952613034 | Bottom plate | |
| 19 | 952761565 | Screw | |
| 20 | 952715072 | Nut | |
| 22 | 952664082 | Slide rail | |
| 23 | 952670219 | Holder front | |
| 24 | 952670221 | Holder back | |
| 25 | 938111494 | Hex. screw | |
| 28 | 952701551 | Roller | |
| 29 | 938111723 | Screw | |
| 30 | 939010410 | Washer | |
| 33 | 952703986 | ldler with sliding pieces | |
| 34 | 952650911 | Spring packet with tension | |
| 35 | 952650912 | Spring packet with tension | |
| 36 | 938111723 | Screw | |
| 37 | 952651156 | Spring washer | |
| 38 | 935541772 | Grease nipple | |
| 39 | 952631222 | Sealing washer | |
| 40 | 952617811 | Bow, compl. | |
| 41 | 49901595 | Cylinder screw | |
| 43 | 952691246 | Wedge | |
| 46 | 952771000 | Hose clamp | |
| 48 | 952771001 | Hose clamp | |
| 49 | 937930232 | Screw | |
| 50 | 504050101 | Crawler right, compl. | |
| 51 | 504050100 | Trolley left, compl. | |
| 60 | Tiltalarm | Tilt alarm |
