Каталог запасных частей к технике: DYNAPAC Dynapac PL2000LS. 504-07145 Steering 1

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
1
2
2
2
2
2
2
3
3
3
3
3
3
4
4
5
5
11
11
11
11
11
11
11
11
11
11
11
11
12
12
12
12
12
12
12
12
12
12
12
12
12
12
12
12
12
12
12
12
12
12
12
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
14
14
15
15
16
16
17
17
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
19
19
19
20
20
21
21
23
23
23
23
24
24
24
24
25
25
26
26
29
29
30
30
30
31
31
32
33
33
34
34
35
35
35
35
35
36
36
37
37
38
38
39
39
40
40
41
41
42
42
43
43
44
44
45
45
45
45
46
46
46
46
46
46
46
47
47
47
47
47
47
47
48
48
48
49
49
50
50
51
51
51
51
51
51
52
52
52
52
52
52
53
53
54
54
55
55
56
56
57
57
60
60
61
61
61
61
62
62
63
63
63
64
64
64
65
65
66
66
66
67
67
67
68
68
69
69
70
70
70
70
71
71
72
72
73
73
74
74
75
75
76
76
77
77
78
78
79
79
80
80
81
81
82
82
83
84
85
85
86
86
87
87
88
88
89
89
89
89
90
90
90
90
91
91
91
91
91
92
Позиция на иллюстрации Заводской номер детали Название детали
504070180 504070180 Steering 1
964725500 964725500 Filter element
1 963176046 Steering block
2 500070565 Counterbalance valve
3 960700730 Housing
4 964006111 Filter
5 930296452 Ball valve
11 961941073 Straight double-ended union
12 961102057 Cutting ring
13 961102007 Union nut
14 504070567 Pipeline
15 504070568 Pipeline
16 961905007 Equal-tee
17 961352008 Double nut
18 961935130 Straight double-ended union
19 961917007 Swivel nut elbow
20 504070564 Pipeline
21 504070565 Pipeline
23 504070590 Pipeline
24 504070591 Pipeline
25 504070674 Pipeline
26 504070675 Pipeline
29 504070676 Pipeline
30 504070677 Pipeline
31 504070546 Pipeline
32 504070545 Pipeline
33 504070544 Pipeline
34 504070543 Pipeline
35 961904007 Union elbow both ports
36 504070547 Pipeline
37 504070548 Pipeline
38 504070596 Pipeline
39 504070597 Pipeline
40 504070592 Pipeline
41 504070540 Pipeline
42 504070539 Pipeline
43 504070542 Pipeline
44 504070541 Pipeline
45 961951184 Straight double-ended union
46 961102068 Cutting ring
47 961102018 Nut
48 961904018 Union elbow both ports
49 504070593 Pipeline
50 504070594 Pipeline
51 961905018 Equal-tee
52 961935118 Straight double-ended union
53 504070582 Pipeline
54 504070584 Pipeline
55 961903018 Straight double-ended union
56 504070512 Pipeline
57 504070549 Pipeline
60 504070516 Pipeline
61 961935106 Stud
62 961919006 Stud
63 961102056 Cutting ring
64 961102006 Union nut
65 961935121 Straight double-ended union
66 961102071 Cutting ring
67 961102021 Nut
68 960860575 Hose
69 960861547 Hose
70 961951185 Straight double-ended union
71 960821551 Hose
72 930211340 Flange half
73 932323729 O-ring
74 508029 Screw
75 960892975 Hose
76 960850355 Hose
77 930211344 Flange half
78 928791 Cylinder screw
79 932313770 O-ring
80 961932096 Straight screwing
81 961934234 Straight double-ended union
82 961935111 Straight double-ended union
83 961102061 Cutting ring
84 961102011 Union nut
85 504070605 Pipeline
86 504070606 Pipeline
87 504070574 Pipeline
88 504070575 Pipeline
89 960830455 Hose
90 960830457 Hose
91 960831201 Hose
92 964805452 Sensor
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
