Каталог запасных частей к технике: DYNAPAC Dynapac PL2000LS. 504-07130 Belt drives

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
1
1
1
1
3
3
4
4
4
4
4
4
4
5
5
5
5
6
6
7
7
8
8
10
10
11
11
12
12
12
13
13
13
15
15
15
16
16
16
16
16
16
16
17
17
18
18
19
19
19
19
20
20
21
21
22
22
23
23
24
24
25
25
26
26
27
27
28
28
28
28
29
29
29
29
30
30
30
30
30
31
31
32
32
33
33
34
34
34
34
35
35
47
47
48
48
48
49
50
50
50
51
52
52
52
52
53
53
53
54
55
55
56
56
57
57
58
58
58
59
59
59
60
60
61
61
Позиция на иллюстрации Заводской номер детали Название детали
504070121 504070121 Belt drive
932785874 932785874 Seal kit for hydr. motor
932785830 932785830 Sealing washer
931701196 931701196 Feather key
932785874 932785874 Seal kit for hydr. motor
1 961935210 Straight double-ended union
3 960862410 Hose
4 930211260 Flange half
5 508053 Screw
6 961935229 Straight double-ended union
7 500070227 Plate
8 961935228 Straight double-ended union
10 961935212 Straight double-ended union
11 960892607 Hose
12 960863677 Hose
13 960861275 Hose
15 961935121 Straight double-ended union
16 932323698 O-ring
17 504070603 Pipeline
18 504070604 Pipeline
19 961917010 Union elbow both ports
20 961102060 Cutting ring
21 961102010 Nut
22 961102058 Cutting ring
23 961102008 Union nut
24 504070505 Pipeline
25 504070506 Pipeline
26 504070507 Pipeline
27 504070508 Pipeline
28 961102071 Cutting ring
29 961102021 Nut
30 961903021 Straight coupling
31 960863775 Hose
32 960863850 Hose
33 960860503 Hose
34 960861300 Hose
35 960860475 Hose
47 500070577 Holder
48 963460011 Flush valve
49 500023 Screw
50 930578860 1ntermediate flange
51 508014 Hex. socket screw
52 961935106 Stud
53 500070580 Pipeline
54 500070581 Pipeline
55 961353064 Screwing
56 961953084 Straight coupling
57 960843007 Hose
58 961102056 Cutting ring
59 961102006 Union nut
60 966057210 Hydraulic motor
61 966057300 Hydraulic motor
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
