Каталог запасных частей к технике: DYNAPAC Dynapac PL2000LS. 500-20120 GfK roof
/87.gif)
1
1
2
3
3
4
5
6
6
7
8
8
9
10
10
11
12
12
13
14
14
15
16
16
17
18
19
19
20
21
21
21
22
23
24
26
27
28
29
30
31
32
33
34
35
36
36
37
37
38
39
39
40
40
41
42
42
43
43
44
44
44
44
45
45
46
47
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 932405055 | 932405055 | O-ring | |
| 663009 | 663009 | GfK roof | |
| 932278303 | 932278303 | Sealing kit | |
| 1 | 500300002 | Roof | |
| 1 | 930450516 | Hose box | |
| 2 | 500300111 | Angle, front right | |
| 3 | 930177510 | Nozzle end | |
| 3 | 500300113 | Angle, front left | |
| 4 | 500300114 | Angle, rear right | |
| 5 | 500300116 | Angle, rear left | |
| 6 | 960845668 | Hose | |
| 6 | 500019 | Screw | |
| 7 | 500200111 | Stop, front left | |
| 8 | 500200138 | Stop, front right | |
| 8 | 500190122 | Vent valve | |
| 9 | 500300200 | Pane, compl. | |
| 10 | 500200107 | Disc | |
| 10 | 964152664 | Filter hausing compl. | |
| 11 | 500300201 | Front frame | |
| 12 | 49100692 | Wiper motor | |
| 12 | 939312380 | Tapping screw | |
| 13 | 49100028 | Wiper arm | |
| 14 | 961935111 | Straight double-ended union | |
| 14 | 49302624 | Set wiper blade | |
| 15 | 39300072 | Rubber clamp profile | |
| 16 | 39300071 | Fill profile | |
| 16 | 960874313 | Hose | |
| 17 | 903645580 | Buffer | |
| 18 | 930280161 | Seal profile | |
| 19 | 500300153 | Roof support, rear | |
| 19 | 500053 | Screw | |
| 20 | 500300006 | Stop, back right | |
| 21 | 965080265 | Hydraulic cylinder | |
| 21 | 500290160 | Pipeline | |
| 22 | 500300004 | Stop, back left | |
| 23 | 960406051 | Locking bar | |
| 24 | 500300123 | Bolt | |
| 25 | 500300124 | Bolt | |
| 26 | 500300125 | Bolt | |
| 27 | 500300126 | Bolt | |
| 28 | 500200143 | Stop angle | |
| 29 | 938366595 | Screw | |
| 30 | 939475275 | Screw | |
| 31 | 500018 | Screw | |
| 32 | 500048 | Screw | |
| 33 | 600006 | Washer | |
| 34 | 500200142 | Bolt | |
| 35 | 930229362 | Friction bearing with collar | |
| 36 | 600011 | Washer | |
| 37 | 936790490 | Split pin | |
| 38 | 930136733 | Bushing | |
| 39 | 600014 | Washer | |
| 40 | 936790545 | Split pin | |
| 41 | 600008 | Washer | |
| 42 | 500234 | Screw | |
| 43 | 704130 | Spring washer | |
| 44 | 600008 | Washer | |
| 45 | 938500008 | Nut | |
| 46 | 49900161 | Screw retention | |
| 47 | 600006 | Washer | |
| 132 | 938150553 | Hex. screw |
