Каталог запасных частей к технике: DYNAPAC Dynapac F181C. Operator Desk extensionable

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
4
5
6
7
8
9
11
12
13
14
15
16
17
18
19
19
20
20
21
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
42
43
44
45
46
47
48
49
50
51
52
53
54
Позиция на иллюстрации Заводской номер детали Название детали
655-03151 655-03151 Operator Desk extensionable
1 977599021 Control knob
2 936730376 Cylinder screw
3 606001 Washer
4 757032417 Washer
5 757032416 Sign board
6 977189860 Potentiometer
7 938399499 Screw
8 939570509 Washer
9 938500054 Safety nut
11 956186314 Lock
12 866031250 Cover hood
13 930404706 Stop bolt
14 654231210 Operator desk
15 756231338 Rearwall
16 939475168 Countersunk screw
17 937930270 Screw
18 49900161 Screw retention
19 930540812 Corrugated pipe
20 930117032 Hose screwing
21 930420611 Counter nut
22 655231322 Hose holder
23 500040 Screw
24 49900080 Screw retention
25 570004 Hex. nut
26 756231344 Supporting frame
27 866021267 Bearing bolt
28 654231245 Roller head
29 866031266 Distance washer
30 936900029 Spring washer
31 938190022 Hex. nut
32 866031271 Locking screw
33 866031272 Knurled nut
34 935171235 Cam roller
35 600011 Washer
36 49900008 Screw retention
37 938191612 Hex. nut
38 756231354 Guide
39 500013 Hex. screw
40 49900080 Screw retention
41 756241382 Plate
42 930540811 Shaft bearing
43 930381000 Precision shaft
44 930229371 Linear bearing assy.
45 508092 Screw
46 606020 Spring washer
47 756231362 Cover hood
48 500138 Hex. screw
49 49900161 Screw retention
50 508059 Screw
51 606020 Spring washer
52 500012 Screw
53 49900080 Screw retention
54 756231381 Plate
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
