Каталог запасных частей к технике: DYNAPAC Dynapac F181C. Engine
4
5
5
5
5
5
5
5
5
5
7
9
11
12
13
13
14
14
15
15
16
16
17
17
18
20
20
22
22
23
23
24
24
25
25
26
27
31
32
33
35
36
37
38
38
38
39
40
41
42
43
44
46
46
47
47
49
49
50
50
51
51
51
52
52
53
53
55
55
55
56
56
57
57
58
58
59
59
67
67
67
68
68
75
76
80
84
84
84
85
85
86
86
87
87
88
88
89
89
90
90
92
93
94
95
96
98
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 654105600 | 654105600 | Engine | |
| 654105661 | 654105661 | Support box | |
| 654105670 | 654105670 | Instrument panel - top | |
| 654105671 | 654105671 | Instrument panel | |
| 654105672 | 654105672 | Instrument panel | |
| 654-09561 | 654-09561 | Engine | |
| 1 | 654105601 | Circuit diagram | |
| 2 | 654105602 | Terminal diagram | |
| 4 | 977514020 | Press button switch | |
| 5 | 977800603 | Indicator lamp module | |
| 7 | 977335752 | Bulb | |
| 9 | 977580228 | Emergency stop switch | |
| 10 | 977580237 | Contact | |
| 11 | 956045500 | Decal, emergency stop | |
| 12 | 977514005 | Press button switch | |
| 13 | 977500501 | Horn | |
| 14 | 500019 | Screw | |
| 15 | 49900161 | Screw retention | |
| 16 | 977041022 | Oil pressure switch | |
| 17 | 977045504 | Temperature transmitter | |
| 18 | 977010512 | Service hour meter | |
| 20 | 977730257 | Relay | |
| 22 | 606003 | Fan disc | |
| 23 | 600004 | Washer | |
| 24 | 977418089 | Rubber cap | |
| 25 | 977455749 | Cover | |
| 25 | 977455748 | Fuse box | |
| 26 | 977454250 | Fuse | |
| 27 | 977454252 | Fuse | |
| 28 | 977454253 | Fuse | |
| 31 | 977459518 | Bridge | |
| 32 | 936750220 | Screw | |
| 33 | Fuselighting | Fuse see lighting Gr. 9 | |
| 35 | 977018411 | Temperature gauge | |
| 36 | 977017242 | Fuel gauge | |
| 37 | 977018412 | Temperature gauge | |
| 38 | 977335672 | Bulb | |
| 39 | 977518011 | Ignition and light switch | |
| 40 | Forwardreverse | Forward reverse lever see drive automatic Gr. 9 | |
| 41 | 956194331 | Key | |
| 42 | 978013748 | Diode | |
| 43 | 977400021 | Plug | |
| 44 | 977407005 | Plug sleeve | |
| 45 | 977396015 | Plug | |
| 46 | 977045109 | Temperature transmitter | |
| 47 | 977510128 | Oil pressure switch | |
| 48 | 977397720 | Socket | |
| 49 | 977455753 | Fuse box, compl. | |
| 50 | 977453072 | Fuse | |
| 51 | 977453070 | Fuse | |
| 52 | 938900516 | Washer | |
| 53 | 533027 | Screw | |
| 55 | 977504059 | Master switch | |
| 56 | 977504060 | Lever | |
| 57 | 533032 | Screw | |
| 58 | 938900516 | Washer | |
| 59 | 938191013 | Nut | |
| 67 | 977022310 | Battery | |
| 68 | 977418421 | Cover for battery poles | |
| 75 | 603060191 | Bridge wire | |
| 76 | 654105576 | Battery, plus cable | |
| 80 | 654105580 | Battery, minus cable | |
| 84 | 977730406 | Relay | |
| 85 | 977729010 | Relay socket | |
| 86 | 936750325 | Screw | |
| 87 | 938900516 | Washer | |
| 88 | 966610060 | Magnet | |
| 89 | 977477183 | Receptacle housing | |
| 90 | 977478302 | Socket contact | |
| 92 | 977463101 | Socket | |
| 93 | 977463102 | Housing | |
| 94 | 977463103 | Contact holder | |
| 95 | 977463106 | Contact | |
| 96 | 977463107 | Contact | |
| 98 | 654105598 | Plate |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
