Каталог запасных частей к технике: DYNAPAC Dynapac F181C. Drive control unit

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
3
3
3
4
4
4
5
5
6
6
7
7
7
8
8
8
9
9
9
9
10
10
10
10
10
10
10
10
11
11
12
12
13
13
14
14
14
14
14
18
18
18
18
18
18
19
19
19
19
19
19
19
19
19
20
20
20
20
20
20
20
21
21
21
22
22
22
22
22
22
23
23
23
24
24
24
24
24
24
24
25
25
36
36
37
37
39
39
39
40
40
40
41
41
41
44
44
44
45
45
46
46
46
46
47
47
48
48
48
49
49
49
49
50
50
50
50
50
50
51
51
52
52
52
53
53
53
54
54
54
55
55
55
55
55
55
55
55
56
56
56
56
57
57
57
57
59
59
59
59
61
61
61
61
61
61
63
63
63
65
65
66
66
68
68
68
68
68
68
68
69
69
69
69
69
69
69
72
72
73
73
74
74
75
75
78
78
78
78
79
79
81
81
81
82
82
82
86
86
87
87
87
88
88
89
89
90
90
90
91
91
91
92
94
94
95
Позиция на иллюстрации Заводской номер детали Название детали
963155704 963155704 Way valve
960644917 960644917 Magnet
657390100 657390100 Drive control unit
1 Pump Pump see split gear box Gr. 7
3 960701210 Adapter plate
4 500040 Screw
5 960854675 Hose
6 960856325 Hose
7 960878550 Hose
8 960875900 Hose
9 960864902 Hose
10 960822300 Hose
11 960861522 Hose
12 960861522 Hose
13 960898512 Hose
14 960820450 Hose
18 930211160 Flange
19 930211260 Flange half
20 932323203 O-ring
21 508053 Screw
22 508053 Screw
23 961772667 Test point
24 961772668 Test connector
25 655390125 Manifold
36 961111012 Non return valve
37 961371710 Plug screw
39 932213250 O-ring
40 930211345 Flange half
41 508029 Screw
44 961174205 Screw
45 990099701 Connection stud
46 961918009 Union tee
47 961121012 Straight coupling
48 961935209 Stud
49 961935212 Straight double-ended union
50 961934201 Straight double-ended union
51 961170059 Blanking plug
52 961932096 Straight screwing
53 961154216 Male connector for swivel nut
54 961935236 Straight double-ended union
55 961935106 Stud
56 961904006 Union elbow both ports
57 961934234 Straight double-ended union
59 990093075 Orifice
61 961918006 Swivel nut run tee
63 961174106 Plug screw
65 956201195 Maintenance indicator
66 990099699 Spring washer
68 961102006 Union nut
69 961102056 Cutting ring
72 960898000 Hose assy
73 960893103 Hose assy
74 960892573 Hose
75 960892573 Hose
78 963155700 Handpump
79 937934290 Hex. screw
81 963135670 Way valve
82 508098 Cylinder screw
86 759390186 Pipeline
87 757390187 Pipeline
88 759390188 Pipeline
89 759390189 Pipeline
90 759390190 Pipeline
91 657390191 Pipeline
92 657390192 Pipeline
94 757390191 Pipeline
95 757390192 Pipeline
