Каталог запасных частей к технике: DYNAPAC Dynapac F181C. Conveyor, auger
5
5
5
7
7
7
11
11
11
13
13
14
14
16
16
17
17
19
22
22
24
27
27
27
27
27
35
35
35
35
35
36
37
37
37
38
38
38
39
40
40
40
41
42
43
44
45
47
48
49
51
52
53
53
54
54
55
55
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 657104500 | 657104500 | Conveyor, auger | |
| 657-09558 | 657-09558 | Conveyor, auger | |
| 1 | 657104501 | Circuit diagram | |
| 2 | 657104502 | Terminal diagram | |
| 5 | Fuse | Fuse see engine Gr. 9 | |
| 7 | 977730406 | Relay | |
| 8 | 977729010 | Relay socket | |
| 9 | 936750325 | Screw | |
| 10 | 938900516 | Washer | |
| 11 | 939570509 | Washer | |
| 13 | 977512167 | Rotary switch | |
| 14 | 977532020 | Toggle switch | |
| 16 | 977184010 | Resistor | |
| 17 | Terminalboard | Terminal board | |
| 18 | Plugconnector | Plug connector see engine Gr. 9 | |
| 19 | Forwardreverse | Forward reverse lever see drive automatic Gr. 9 | |
| 22 | 978013748 | Diode | |
| 24 | 978014110 | Diode plate | |
| 27 | 977418058 | Cable protection hood | |
| 27 | 977478231 | Sealing | |
| 27 | 977477117 | Receptacle housing | |
| 27 | 654104427 | Plug socket, compl. | |
| 27 | 977478301 | Contact | |
| 35 | 722104435 | Set value box | |
| 36 | 722104436 | Clamp box | |
| 37 | 977189850 | Potentiometer | |
| 38 | 977599011 | Adjustment knob | |
| 39 | 990000924 | Label | |
| 40 | 978008052 | Prop. amplifier | |
| 41 | 936750225 | Screw | |
| 42 | 606001 | Washer | |
| 43 | 977415011 | Union nut | |
| 44 | 977416711 | Nut | |
| 45 | 977416451 | Sealing | |
| 46 | 722104446 | Plate | |
| 47 | 936750325 | Screw | |
| 48 | 938900516 | Washer | |
| 49 | 756400237 | Holder | |
| 51 | 500021 | Screw | |
| 52 | 500026 | Screw | |
| 53 | 600006 | Washer | |
| 54 | 49900161 | Screw retention | |
| 55 | 929233 | Nut |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
