Каталог запасных частей к технике: DYNAPAC Dynapac F1800C. 4812024436A Hydraulic, work hydraulic 1

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
2
2
2
2
7
7
8
8
8
9
10
10
11
12
12
12
12
13
14
15
15
15
16
16
16
16
17
18
18
19
19
20
20
20
21
22
22
23
23
24
24
25
27
27
27
27
28
30
30
30
32
32
32
33
33
34
35
35
36
37
37
37
38
39
41
41
42
42
42
43
43
44
44
45
46
47
48
49
50
51
51
52
52
53
55
56
57
58
59
59
61
61
62
62
62
62
63
63
Позиция на иллюстрации Заводской номер детали Название детали
2 4812018005 Control block
7 4812045781 Male connector
8 D961935108 Straight double-ended union
9 D961935128 Straight double-ended union
10 D961935234 Male connector
11 D961935206 Male connector
12 D961941086 Male connector
13 D961917011 Elbow socket
14 D961935111 Straight double-ended union
15 D961935106 Male connector
16 D961935103 Straight double-ended union
17 D961772617 Test connector
18 D961941073 Male connector
19 D961353009 Male connector
20 D961919006 Stud
21 D961355037 Swivel nut branch tee
22 D961917006 Elbow socket
23 D961917007 Elbow socket
24 4812039588 Elbow union
25 4812014047 Hose
27 4812013520 Hose
28 4812013494 Hose
30 4812013492 Hose
32 4812013648 Hose
33 4812013488 Hose
34 4812013515 Hose
35 4812014034 Pipeline
36 4812013637 Hose
37 4812013647 Hose
38 D961935213 Straight screwing
39 4812013495 Hose
41 4812013487 Hose
42 4812013493 Hose
43 D961907007 Bulkhead union elbow
44 4812013518 Hose
45 D961835209 Straight double-ended union
46 D961919009 Stud
47 D961355038 Elbow union
48 4812012789 Valve support
49 4812014727 Add-on kit
49.1 0147135003 Hexagon head screw
49.2 0147196448 Hexagon head screw
50 4812015111 Hose
51 4812015440 Hose
52 D961906007 Bulk head union
53 D961355008 Reduction screwing
55 4812015460 Hose
56 4812045921 Hose
57 4812008707 Hose
58 4812024254 Pipeline
59 4812024973 Hose
61 4812201440 Hose
62 4812035634 Hose
63 4812201532 Pipeline
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
