Каталог запасных частей к технике: DYNAPAC Dynapac F1800C. 4812012320 Cable W27
Y12A
Y12A.1
Y12A.2
Y12A.3
Y12A.3
Y12B
Y12B.1
Y12B.2
Y13A
Y13A.1
Y13A.2
Y13A.3
Y13B
Y13B.1
Y13B.2
Y13B.3
Y14A
Y14A.1
Y14A.2
Y14A.3
Y14B
Y14B.1
Y14B.2
Y14B.3
Y15A
Y15A.1
Y15A.2
Y15A.3
Y15B
Y15B.1
Y15B.2
Y15B.3
Y23
Y23.1
Y23.2
Y23.3
Y24
Y24.1
Y24.2
Y24.3
X7
X7
X7.1
X7.2
Y3
Y3.1
Y3.2
Y3.3
X3
X3
X3.1
X3.2
Y9A
Y9A.1
Y9B
Y9B.1
Y10A
Y10A.1
Y10B
Y10B.1
Y11A
Y11A.1
Y11B
Y11B.1
Y16A
Y16A.1
Y16A.2
Y16A.3
Y16B
Y16B.1
Y16B.2
Y16B.3
Y18A
Y18A.1
Y18A.2
Y18A.3
Y18B
Y18B.1
Y18B.2
Y18B.3
Y19A
Y19A.1
Y19A.2
Y19A.3
Y19B
Y19B.1
Y19B.2
Y19B.3
Y20A
Y20A.1
Y20A.2
Y20A.3
Y20B
Y20B.1
Y20B.2
Y20B.3
Y21A
Y21A.1
Y21A.2
Y21A.3
Y21B
Y21B.1
Y21B.2
Y21B.3
Y22A
Y22A.1
Y22A.2
Y22A.3
Y22B
Y22B.1
Y22B.2
Y22B.3
Y25A
Y25A.1
Y25A.2
Y25A.3
Y26
Y26.1
Y26.2
Y26.3
X8
X8
X8.2
X8.1
Y28A
Y28A.1
Y28A.2
Y28A.3
Y28B
Y28B.1
Y28B.2
Y28B.3
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| Y12A | Y12A | Electrical components | |
| Y12A.1 | D977466134 | Socket shell | |
| Y12A.2 | D977466144 | Socket contact | |
| Y12A.3 | D977466137 | Key | |
| Y12B | Y12B | Electrical components | |
| Y12B.1 | D977466134 | Socket shell | |
| Y12B.2 | D977466144 | Socket contact | |
| Y12B.3 | D977466137 | Key | |
| Y13A | Y13A | Electrical components | |
| Y13A.1 | D977466134 | Socket shell | |
| Y13A.2 | D977466144 | Socket contact | |
| Y13A.3 | D977466137 | Key | |
| Y13B | Y13B | Electrical components | |
| Y13B.1 | D977466134 | Socket shell | |
| Y13B.2 | D977466144 | Socket contact | |
| Y13B.3 | D977466137 | Key | |
| Y14A | Y14A | Electrical components | |
| Y14A.1 | D977466134 | Socket shell | |
| Y14A.2 | D977466144 | Socket contact | |
| Y14A.3 | D977466137 | Key | |
| Y14B | Y14B | Electrical components | |
| Y14B.1 | D977466134 | Socket shell | |
| Y14B.2 | D977466144 | Socket contact | |
| Y14B.3 | D977466137 | Key | |
| Y15A | Y15A | Electrical components | |
| Y15A.1 | D977466134 | Socket shell | |
| Y15A.2 | D977466144 | Socket contact | |
| Y15A.3 | D977466137 | Key | |
| Y15B | Y15B | Electrical components | |
| Y15B.1 | D977466134 | Socket shell | |
| Y15B.2 | D977466144 | Socket contact | |
| Y15B.3 | D977466137 | Key | |
| Y23 | Y23 | Electrical components | |
| Y23.1 | D977466134 | Socket shell | |
| Y23.2 | D977466144 | Socket contact | |
| Y23.3 | D977466137 | Key | |
| Y24 | Y24 | Electrical components | |
| Y24.1 | D977466134 | Socket shell | |
| Y24.2 | D977466144 | Socket contact | |
| Y24.3 | D977466137 | Key | |
| X7 | X7 | Electrical components | |
| X7.1 | 4812046266 | Power-timer housing | |
| X7.2 | 4812030987 | Female contact | |
| Y3 | Y3 | Electrical components | |
| Y3.1 | D977476437 | Elbow plug grau/ grey | |
| Y3.2 | 4812044724 | Sealing | |
| Y3.3 | 4812045784 | Screw | |
| X3 | X4 | Electrical components | |
| X3.1 | 4812029619 | Power-timer housing | |
| X3.2 | 4812030987 | Female contact | |
| Y9A | Y9A | Electrical components | |
| Y9A.1 | 4812029030 | Valve plug | |
| Y9B | Y9B | Electrical components | |
| Y9B.1 | 4812029030 | Valve plug | |
| Y10A | Y10A | Electrical components | |
| Y10A.1 | 4812029030 | Valve plug | |
| Y10B | Y10B | Electrical components | |
| Y10B.1 | 4812029030 | Valve plug | |
| Y11A | Y11A | Electrical components | |
| Y11A.1 | 4812029030 | Valve plug | |
| Y11B | Y11B | Electrical components | |
| Y11B.1 | 4812029030 | Valve plug | |
| Y16A | Y16A | Electrical components | |
| Y16A.1 | 4812029030 | Valve plug | |
| Y16A.2 | 4812044724 | Sealing | |
| Y16A.3 | 4812045784 | Screw | |
| Y16B | Y16B | Electrical components | |
| Y16B.1 | 4812029030 | Valve plug | |
| Y16B.2 | 4812044724 | Sealing | |
| Y16B.3 | 4812045784 | Screw | |
| Y18A | Y18A | Electrical components | |
| Y18A.1 | 4812029030 | Valve plug | |
| Y18A.2 | 4812044724 | Sealing | |
| Y18A.3 | 4812045784 | Screw | |
| Y18B | Y18B | Electrical components | |
| Y18B.1 | 4812029030 | Valve plug | |
| Y18B.2 | 4812044724 | Sealing | |
| Y18B.3 | 4812045784 | Screw | |
| Y19A | Y19A | Electrical components | |
| Y19A.1 | 4812029030 | Valve plug | |
| Y19A.2 | 4812044724 | Sealing | |
| Y19A.3 | 4812045784 | Screw | |
| Y19B | Y19B | Electrical components | |
| Y19B.1 | 4812029030 | Valve plug | |
| Y19B.2 | 4812044724 | Sealing | |
| Y19B.3 | 4812045784 | Screw | |
| Y20A | Y20A | Electrical components | |
| Y20A.1 | 4812029030 | Valve plug | |
| Y20A.2 | 4812044724 | Sealing | |
| Y20A.3 | 4812045784 | Screw | |
| Y20B | Y20B | Electrical components | |
| Y20B.1 | 4812029030 | Valve plug | |
| Y20B.2 | 4812044724 | Sealing | |
| Y20B.3 | 4812045784 | Screw | |
| Y21A | Y21A | Electrical components | |
| Y21A.1 | 4812029030 | Valve plug | |
| Y21A.2 | 4812044724 | Sealing | |
| Y21A.3 | 4812045784 | Screw | |
| Y21B | Y21B | Electrical components | |
| Y21B.1 | 4812029030 | Valve plug | |
| Y21B.2 | 4812044724 | Sealing | |
| Y21B.3 | 4812045784 | Screw | |
| Y22A | Y22A | Electrical components | |
| Y22A.1 | 4812029030 | Valve plug | |
| Y22A.2 | 4812044724 | Sealing | |
| Y22A.3 | 4812045784 | Screw | |
| Y22B | Y22B | Electrical components | |
| Y22B.1 | 4812029030 | Valve plug | |
| Y22B.2 | 4812044724 | Sealing | |
| Y22B.3 | 4812045784 | Screw | |
| Y25A | Y25A | Electrical components | |
| Y25A.1 | 4812029030 | Valve plug | |
| Y25A.2 | 4812044724 | Sealing | |
| Y25A.3 | 4812045784 | Screw | |
| Y26 | Y26 | Electrical components | |
| Y26.1 | 4812029030 | Valve plug | |
| Y26.2 | 4812044724 | Sealing | |
| Y26.3 | 4812045784 | Screw | |
| X8 | X8 | Electrical components | |
| X8.2 | 4812030987 | Female contact | |
| X8.1 | 4812046267 | Power timer housing | |
| Y28A | Y28A | Electrical components | |
| Y28A.1 | 4812029030 | Valve plug | |
| Y28A.2 | 4812044724 | Sealing | |
| Y28A.3 | 4812045784 | Screw | |
| Y28B | Y28B | Electrical components | |
| Y28B.1 | 4812029030 | Valve plug | |
| Y28B.2 | 4812044724 | Sealing | |
| Y28B.3 | 4812045784 | Screw |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
