Позиция на иллюстрации
Заводской номер детали
Название детали
1
D450163401
Reversing roller
2
4730013391
Support tube
3
D450163302
Intermediate ring
4
D936032112
Circlip
5
4749500021
Bearing
6
D932596000
Nilosring
7
0295311300
Grooved nut
8
4749302123
Tube pole cap
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
