Каталог запасных частей к технике: DYNAPAC Dynapac CC800. Hydraulic propulsion and brake system pump
/24.gif)
5
6
7
8
9
10
10
12
13
16
17
18
19
26
29
30
30
31
32
33
33
34
39
40
40
40
41
42
43
44
45
46
47
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 4 | 4700313102 | Cable ties | |
| 5 | 4812119960 | Hydraulic pump | |
| 6 | 4700904703 | Plain washer | |
| 7 | 4700500037 | Hex. screw | |
| 8 | 4812120635 | Measuring nipple | |
| 9 | 4700904727 | Adapter | |
| 10 | 4700791699 | Elbow 90° | |
| 12 | 4700792332 | Elbow 90 orfs | |
| 13 | 4700791743 | Straight connector orfs | |
| 16 | 4700483689 | Hydraulic hose | |
| 17 | 4700483690 | Hydraulic hose | |
| 18 | 4700389403 | Hydraulic hose | |
| 19 | 4700389404 | Hydraulic hose | |
| 26 | 4700483665 | Hydraulic hose | |
| 29 | 4700389400 | Hydraulic hose | |
| 30 | 4700483652 | Hydraulic hose | |
| 31 | 4812120636 | Hydraulic hose | |
| 32 | 4700483714 | Hydraulic hose | |
| 33 | 4700313001 | Clamp | |
| 34 | 4700313108 | Hose clamp | |
| 39 | 4700904009 | O-ring | |
| 40 | 4700791538 | Straight connector | |
| 41 | Hydraulictank | Hydraulic tank | |
| 42 | Radiator | Radiator, cpl | |
| 43 | Valve | Valve | |
| 44 | 4700791543 | Elbow 45° | |
| 45 | 4700791745 | Elbow 90, O-ring with swivel | |
| 46 | 4700791541 | Straight connector | |
| 47 | 4700483688 | Hydraulic hose |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
