Каталог запасных частей к технике: DYNAPAC Dynapac CC422. Offset drum
1
1
1
1
1
3
4
5
6
6
7
9
10
11
11
12
12
12
12
13
13
14
15
17
17
20
21
22
23
24
24
25
25
26
26
30
30
35
39
41
42
42
42
42
59
59
60
62
64
65
67
68
69
69
70
70
71
72
100
100
100
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 380780 | Direction control valve | |
| 1 | 381217 | Direction control valve | |
| 1 | 377432 | Direction control valve | |
| 3 | 381029 | Holder plate | |
| 4 | 500021 | Screw | |
| 5 | 570005 | Nut | |
| 6 | 904229 | Washer 8,4x16x1,5 | |
| 7 | 500053 | Screw | |
| 9 | 373406 | Cylinder, offset drum | |
| 10 | 801198 | Elbow 90 | |
| 11 | 371437 | Shaft | |
| 12 | 903786 | Washer | |
| 13 | 630020 | Pin | |
| 14 | 334197 | Elbow 90 | |
| 15 | 234388 | Connector | |
| 17 | Hydraulichose | Hydraulic hose | |
| 20 | 334121 | Adapter | |
| 21 | 234953 | Connector | |
| 22 | 330171 | Hollow screw | |
| 23 | 162024 | Washer, sealing | |
| 24 | 483514 | Hydraulic hose | |
| 25 | 482989 | Hydraulic hose | |
| 26 | 371419 | Hydraulic hose | |
| 30 | Existing | Existing | |
| 35 | 359192 | Bearing | |
| 39 | 926214 | Grease fitting | |
| 41 | 373183 | Elbow 90 | |
| 42 | 903813 | Hydraulic hose | |
| 59 | 903082 | Hose shield | |
| 60 | 334236 | Adapter | |
| 62 | 334389 | Connector | |
| 64 | 334196 | Elbow 90 | |
| 65 | Notused | Not used on this model | |
| 67 | 903422 | Decal SAFETY | |
| 68 | 921022 | Hose clamp | |
| 69 | 903831 | Nut | |
| 70 | 904231 | Washer 13x24x2 | |
| 71 | 924731 | Connector | |
| 72 | 234662 | Elbow 45 | |
| 100 | Existingparts | Existing parts |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
