Dynapac Compaction Equipment AB СС422 SN 42520422, -CC422106
Service kits
Service kits
939563 Service kit 50 h
939564 Service kit 500 h
939565 Service kit 1000 h
Repair kits
Repair kits
938905 Eccentric shaft kit
938891 Drum rotation kit
938917 Scraper kit CC322/422/432
945720 Scraper kit CC322/422/432
938888 Shock absorber kit, drum
938558 Steering hitch kit
Frames
Covers, ladders
Scrapers, standard, front drum Up to 42520969
Scrapers, standard, rear drum Up to 42520969
Scrapers, standard From 42520970
Scrapers, spring loaded Foldable Up to 42520969
Scrapers, spring loaded, front drum From 42520970
Scrapers, spring loaded, rear drum From 42520970
Articulated link
Structure
Noise suppression
Noise reduction hood
Sprinkler systems, tanks
Sprinkler system, front Up to 42520969
Sprinkler system, front From 42520970
Sprinkler system, rear Up to 42520969
Sprinkler system, rear From 42520970
Drum, standard, front/rear
Diesel engine Cummins 4B3.9 TAA Up to 42520716
Diesel engine Cummins 4B3.9 TAA From 42520717
Cooling system
Intake system
Fuel system
Exhaust system
Pumpdrive and coupling
373354 Gear box
Propulsion system, pump Up to 42520696
359142 Hydraulic pump, propulsion
Propulsion system, pump From 42520697
Propulsion system, motors Up to 42520696
Propulsion system, motors From 42520697
Vibration system, pump
359140 Valve Vibration
Vibration system, motors
370260 Hydraulic motor, vibration
Steering system Up to 42520906
359145 Steering valve
375031 Hydraulic cylinder
Hydraulic oil tank
Steering system From 42520907
Offset drum
381217 Direction control valve
380780 Direction control valve
Brake system
Electrical equipment
Electric battery switch
Instrument box
Instrument panel, main
Speed and frequency, sensors
Instrument panel, upper left
Instrument panel, upper right
Instrument panel, lower left
Instrument panel, lower right
Instrument panel, relay, fuses
Emergency stop panel
Driving lights Direction & licenseplate light
Working lights with/without Rops
Working lights, cab
Working lights, Xenon lamp
Protection cover, Head light
Rotating beacon
Tachograph
Drivers platform
Drivers platform, for cab
Drivers seat, turn-over Up to 42520933
Drivers seat, turn-over From 42520934
Drivers seat turn-over in cab Up to 42520933
Drivers seat, turn-over in cab From 42520934
359918 Steering column Up to 42520933
391163 Steering column From 42520934
Cross sliding Controls
Cross sliding Carrier
Forward and reverse control
Speed limiter Option
Engine control
Rear mirror
Rops/fops
Cab, interior
Cab, screens
Cab, inside panels
Cab, wipers, right side
Cab, wipers, front and rear
Cab, door, left side
Cab, door, left side (3-split)
Cab, heater and, fan system
385770 Heater unit
Cab, roof mounted, electrical switches
Cab Interior
Cab Screens
Cab Inside panels
Cab, water tank wipers
Cab, sun curtain, first aid kit, int mirror
Exterior rear mirrors
Radio and cassette/cd player
Plates and decals
Standard equipment
Compaction meter
Edge cutter
Edge cutter Hydraulics without offset
Edge cutter Hydraulics with offset
Edge cutter Sprinkler system
Eyelet
SMV sign
Tool equipment
Air conditioner assembly
Condensor assembly
385587 Heater/AC unit
Compressor assembly
Roof hatch
Asphalt temperature meter
72
73
74
75
75
75
75
76
76
77
78
79
80
81
82
83
84
Позиция на иллюстрации
Заводской номер детали
Название детали
72
287713
Solenoid valve
73
792288
Hose connector
74
901431
Hose connection
75
904878
Hose reinforced
76
313001
Hose clamp
77
372315
Bracket
78
500013
Hex. screw
79
904228
Washer 6,4x12x1,5
80
376191
Ground cable
81
313041
Cable ties
82
535003
Screw
83
925958
Connection
84
904588
Cable harness
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
