Каталог запасных частей к технике: DYNAPAC Dynapac CC322. Steering system From 62111100
1
2
4
5
5
6
7
7
8
9
10
11
13
13
15
15
16
18
18
20
21
24
24
25
25
26
41
42
45
46
47
48
49
49
50
51
53
55
56
61
62
63
64
66
70
73
74
75
75
78
79
80
81
82
83
84
85
86
87
90
91
92
93
93
97
98
99
101
102
103
104
104
105
105
106
106
107
108
109
109
110
111
112
113
114
115
116
200
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 395952 | Hydraulic pump | |
| 2 | 359139 | Pilot valve | |
| 4 | 392002 | Steering cylinder | |
| 5 | 813316 | Ball bushing | |
| 6 | 923378 | Hose clamp | |
| 7 | 376040 | Hydraulic hose | |
| 8 | 232119 | Split flange | |
| 9 | 500029 | Screw | |
| 10 | 904637 | Washer 10x18x2 | |
| 11 | 813443 | O-ring | |
| 13 | 483698 | Hydraulic hose | |
| 15 | 482990 | Hydraulic hose | |
| 16 | 924731 | Connector | |
| 18 | 482995 | Hydraulic hose | |
| 20 | 334524 | Connector | |
| 21 | 234953 | Connector | |
| 24 | 482917 | Hydraulic hose | |
| 25 | 482918 | Hydraulic hose | |
| 26 | 334420 | Elbow 90 | |
| 41 | 508096 | Screw | |
| 42 | 904637 | Washer 10x18x2 | |
| 45 | 359632 | Hydraulic oil tank | |
| 46 | 359639 | Cover | |
| 47 | 357138 | Ventilating filter | |
| 48 | 357139 | Connector | |
| 49 | 313008 | Hose clamp | |
| 50 | 205067 | Rubber hose | |
| 51 | 989151 | Oil level gauge | |
| 53 | 929122 | Reducing | |
| 55 | 334143 | Straight connector | |
| 56 | 334203 | Elbow 90, O-ring | |
| 61 | 334121 | Adapter | |
| 62 | 357141 | O-ring | |
| 63 | 357459 | Rubber cloth | |
| 64 | 500053 | Screw | |
| 66 | 500028 | Screw | |
| 70 | 910161 | Measuring nipple | |
| 73 | 904567 | Washer 10,5x28x6 | |
| 74 | 232122 | Plug 3/4NPTF | |
| 75 | 892446 | Plug | |
| 78 | 359647 | Hose clamp | |
| 79 | 359648 | Hose clamp | |
| 80 | 359649 | Hose clamp | |
| 81 | 359650 | Hose clamp | |
| 82 | 902286 | Lock nut M8 | |
| 83 | 313102 | Cable ties | |
| 84 | 500061 | Screw | |
| 85 | 902285 | Lock nut M6 | |
| 86 | 334461 | Reducing | |
| 87 | 433830401 | Connector | |
| 88 | 502036 | Screw | |
| 89 | 904567 | Washer 10,5x28x6 | |
| 90 | 903082 | Hose shield | |
| 91 | 371519 | Holder plate | |
| 92 | 904556 | Washer 8,4x16x3,0 | |
| 93 | 500021 | Screw | |
| 97 | 370155 | Valve block | |
| 98 | 160287 | O-ring | |
| 99 | 903773 | Screw | |
| 101 | 235002 | Connector | |
| 102 | 904115 | Bulkhead elbow | |
| 103 | 234512 | Bulkhead union | |
| 104 | 482257 | Hydraulic hose | |
| 105 | 482992 | Hydraulic hose | |
| 106 | 482993 | Hydraulic hose | |
| 107 | 603009 | Washer | |
| 108 | 371669 | Straight connector | |
| 109 | 903812 | Hydraulic hose | |
| 110 | 903831 | Nut | |
| 111 | 904231 | Washer 13x24x2 | |
| 112 | 926214 | Grease fitting | |
| 113 | 372680 | Bracket | |
| 114 | 921119 | Pipe clamp | |
| 115 | 904229 | Washer 8,4x16x1,5 | |
| 116 | 234662 | Elbow 45 | |
| 200 | Existingparts | Existing parts |
