Каталог запасных частей к технике: DYNAPAC Dynapac CC322. Drivers platform For cab
2
3
4
4
5
6
6
7
8
9
10
10
11
12
13
14
14
14
19
20
20
21
21
22
22
25
26
27
28
28
29
29
30
30
31
32
33
33
35
35
37
38
39
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | Cab,interior | Cab, interior | |
| 2 | Crosssliding | Cross sliding | |
| 3 | 359418 | Linear bearing | |
| 4 | 500021 | Screw | |
| 5 | 359885 | Locking rail | |
| 6 | 513013 | Screw | |
| 7 | 500029 | Screw | |
| 8 | 904557 | Washer 10,5x22x4 | |
| 9 | Driversseat | Drivers seat | |
| 10 | 359887 | Shock absorber | |
| 11 | 359888 | Shock absorber | |
| 12 | 359889 | Shaft | |
| 13 | 570005 | Nut | |
| 14 | 904556 | Washer 8,4x16x3,0 | |
| 19 | Forwardandreverse | Forward and reverse control | |
| 20 | 359892 | Cover plate | |
| 21 | 500019 | Screw | |
| 22 | 904229 | Washer 8,4x16x1,5 | |
| 25 | 359894 | Shock absorber | |
| 26 | 359895 | Brush profile | |
| 27 | 903731 | Blind rivet | |
| 28 | 903290 | Washer 21x36x6 | |
| 29 | 359998 | Back-up ring | |
| 30 | 924823 | Screw | |
| 31 | 904233 | Washer 21x36x3 | |
| 32 | 586022 | Lock nut M20 | |
| 33 | 500194 | Screw | |
| 35 | 372704 | Holder | |
| 37 | 370662 | Spacer | |
| 38 | 373227 | Spacer | |
| 39 | 500013 | Hex. screw | |
| 47 | 371621 | Bellows | |
| 48 | 313041 | Cable ties | |
| 49 | 904698 | Washer 4,3x8x0,8 | |
| 50 | 624004 | Pop rivet | |
| 51 | 371129 | Noise suppression box, cpl | |
| 52 | 371395 | Cover | |
| 53 | 600004 | Washer | |
| 54 | 500012 | Screw | |
| 55 | 371396 | Cover | |
| 56 | 371599 | Cover | |
| 57 | 513008 | Screw | |
| 58 | 385932 | Spacer bracket | |
| 59 | 603009 | Washer | |
| 60 | 500047 | Screw | |
| 61 | 904556 | Washer 8,4x16x3,0 |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
