Каталог запасных частей к технике: DYNAPAC Dynapac CC322. Cab, door, left side
24
28
28
132
133
160
161
164
165
166
168
169
169
170
171
172
173
174
175
176
177
178
179
181
182
183
184
186
187
188
189
190
192
193
194
195
196
197
198
199
200
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 908354 | 908354 | Mounting kit | |
| 902866 | 902866 | Key Marked 455 | |
| 936897 | 936897 | Door, cpl | |
| 939469 | 939469 | Handle | |
| 24 | 586003 | Lock nut M8 | |
| 28 | 901315 | Screw | |
| 132 | 500012 | Screw | |
| 133 | 541702 | Screw M6x12 | |
| 160 | 908566 | Door frame, left | |
| 161 | 908567 | Cover | |
| 164 | 908568 | Edge trim | |
| 165 | 908569 | Cover | |
| 166 | 908570 | Cover | |
| 168 | 908571 | Cover | |
| 169 | 903805 | Screw | |
| 170 | 937406 | Screen | |
| 171 | 908545 | Seal list | |
| 172 | 908572 | List | |
| 173 | 903782 | Screw | |
| 174 | 937407 | Screen | |
| 175 | 908573 | Sealing | |
| 176 | 908574 | Sealing | |
| 177 | 908575 | Slide bar | |
| 178 | 908545 | Seal list | |
| 179 | 937408 | Screen | |
| 181 | 908284 | Gas spring | |
| 182 | 908576 | Ball joint | |
| 183 | 570005 | Nut | |
| 184 | 904229 | Washer 8,4x16x1,5 | |
| 186 | 935244 | Door handle with key | |
| 187 | 908577 | Washer | |
| 188 | 908578 | Washer | |
| 189 | 908579 | Leader | |
| 190 | 908287 | Lock | |
| 192 | 903802 | Screw | |
| 193 | 908580 | Lock pin | |
| 194 | 908581 | Washer | |
| 195 | 908582 | Cover | |
| 196 | 908583 | Bracket | |
| 197 | 513025 | Screw | |
| 198 | 508001 | Cylinder screw | |
| 199 | 908584 | Rubber seal | |
| 200 | 937056 | Hinge, cpl |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
