1
2
3
4
4
4
5
5
6
7
8
8
9
10
11
12
13
14
15
16
17
18
Позиция на иллюстрации
Заводской номер детали
Название детали
1
4700397606
Protective cover bracket
2
4700397607
Protective cover bracket
3
4812110210
Protective cover bracket
4
4700904640
Washer
5
4700500053
Hex. screw
6
4700792801
Turn fastener
7
4700923253
Rivet
8
4812110211
Protective cover
9
4700615050
Washer
10
4700500053
Hex. screw
11
4700397399
Bar
12
4700904557
Washer
13
4700500048
Hex. screw
14
4811000112
Catching belt
15
4811000113
Catching belt
16
4700313041
Cable tie
17
4700500021
Hex. screw
18
4700570005
Hex. nut
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
