Каталог запасных частей к технике: DYNAPAC Dynapac CC2200C. Engine structure

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
4
5
5
5
5
6
6
7
7
7
8
9
9
9
10
11
12
13
14
15
16
17
18
19
20
21
21
22
22
22
22
22
22
23
23
23
23
24
25
25
26
27
28
29
29
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
46
46
47
48
49
50
51
52
53
Позиция на иллюстрации Заводской номер детали Название детали
1 Enginestructure Engine structure
2 4812121578 Engine cover, right
3 4812121581 Engine cover, left
4 Hosesupport Hose support
5 4700904229 Washer
6 4700500022 Hex. screw
7 4700586003 Hexagon lock nut
8 4700392799 Grid
9 4700904640 Washer
10 4700500021 Hex. screw
11 4700379992 Plug
12 4700903768 Threaded stud
13 4700570005 Hex. nut
14 4700390229 Rubber cloth
15 4700615050 Washer
16 4700500053 Hex. screw
17 4700792325 Blind rivet
18 4700396542 Lock bracket
19 4700926215 Protective plug
20 4700389857 Threaded plate
21 4700513017 Screw
22 4700904735 Steel plain washer
23 4700586002 Lock nut
24 4700391157 Connection block
25 4700904230 Washer
26 4700500092 Screw
27 4700570006 Hex. nut
28 4700791823 Adapter
29 4700791799 Straight connector orfs
30 4700792334 Elbow 90 orfs
31 4700791231 Adapter
32 4700791840 Adapter
33 4700792825 Blind insert nut
34 4700792326 Stud
35 4700903456 Pipe clamp
36 4700791711 Pipe clamp
37 4700791712 Cover plate
38 4700904637 Washer
39 4700500048 Hex. screw
40 4700792441 Cable tie with holder
41 4700389859 Shims
42 4812114795 Bracket
43 4812114521 Battery box
44 4812115293 Cover
45 4700500013 Hex. screw
46 4700500015 Hex. screw
47 4812115286 Bracket
48 4700500019 Hex. screw
49 4700904228 Steel plain washer
50 4700500185 Screw
51 4700500506 Screw
52 4812118232 Battery insulation
53 4812118233 Battery insulation
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
