Каталог запасных частей к технике: DYNAPAC Dynapac CC142. Scrapers, spring loaded, front drum Up to 602X2850
1
2
3
4
5
6
8
8
9
10
11
12
13
14
14
15
15
16
16
17
17
17
18
19
20
21
22
23
24
25
26
40
40
41
41
42
42
43
44
46
46
47
48
48
48
48
49
49
50
50
50
50
52
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 4700387806 | Scraper bracket | |
| 2 | 4700387807 | Scraper bracket | |
| 3 | 4700387808 | Scraper bracket | |
| 4 | 4700387809 | Scraper bracket | |
| 5 | 4700358874 | Stop | |
| 6 | 4700385613 | Hook | |
| 8 | 4700358876 | Spring | |
| 9 | 4700380255 | Screw | |
| 10 | 4700500015 | Hex. screw | |
| 11 | 4700500047 | Hexagon head screw | |
| 12 | 4700500046 | Hex. head screw | |
| 13 | 4700500133 | Screw | |
| 14 | 4700904228 | Steel plain washer | |
| 15 | 4700904229 | Washer | |
| 16 | 4700904230 | Washer | |
| 17 | 4700904231 | Washer | |
| 18 | 4700904703 | Plain washer | |
| 19 | 4700586002 | Lock nut | |
| 20 | 4700791182 | Nut | |
| 21 | 4700586018 | Lock nut | |
| 22 | 4700586019 | Lock nut | |
| 23 | 4700791082 | Screw | |
| 24 | 4700570006 | Hex. nut | |
| 25 | 4700904241 | Screw | |
| 26 | 4700570005 | Hex. nut | |
| 40 | 4700384050 | Scraper bracket | |
| 41 | 4700385673 | Scraper bracket | |
| 42 | 4700385218 | Scraper | |
| 43 | 4700384493 | Spacer sleeve | |
| 44 | 4700500056 | Screw | |
| 46 | 4700904342 | Screw | |
| 47 | 4700904343 | Screw | |
| 48 | 4700904231 | Washer | |
| 49 | 4700904703 | Plain washer | |
| 50 | 4700586019 | Lock nut | |
| 52 | 4700500111 | Screw |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
