Позиция на иллюстрации
Заводской номер детали
Название детали
1
4812111768
Hydraulic block
2
4700792339
Adapter
3
4700791212
Adapter
4
4812111771
Hose holder
5
4812111770
Holder
6
4812114492
Bulkhead union
7
4700904229
Washer
8
4700500019
Hex. screw
9
4700500090
Screw
10
4700904556
Steel plain washer
11
4700500022
Hex. screw
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
