Pad shell assy, Special field kt 18176
Pad shell 18170
Fire extinguisher assembly 17810
Heater, Simple cab Option 18163
385222 Heater 17784
1
1
2
3
3
3
4
4
4
4
5
5
6
7
8
9
10
11
12
13
14
15
16
Позиция на иллюстрации
Заводской номер детали
Название детали
1
377001
Pad shell
2
500286
Screw
3
586022
Lock nut M20
4
904233
Washer 21x36x3
5
500098
Screw
6
377070
Scraper bracket
7
376551
Scraper tooth
8
376622
Holder
9
500165
Screw
10
904232
Washer 17x30x3
11
500070
Screw M16x50
12
904558
Washer 17x30x6
13
382572
Mounting screw
14
570015
Nut M20
15
382571
Hexagon sleeve
16
Crossbeam
Cross beam
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
