Levelling blade, metal parts
Levelling blade, hydraulic parts
Levelling blade control
Air conditioner assembly Up to 68X20851
Air conditioner unit
Air conditioner assembly From 68X20852
Condensor assembly
Compressor assembly
Evaporator assambly
Anti spin CA
Anti spin, Potentiometer installation
Anti spin, Hydraulic
Roof hatch
Pad shell
Scraper and beam
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
17
18
19
19
20
20
20
20
21
21
22
22
23
23
24
24
25
26
27
28
28
28
29
29
29
30
30
30
31
31
32
Позиция на иллюстрации
Заводской номер детали
Название детали
1
801199
Adapter
2
346230
Clamp
3
500022
Screw
4
356273
Spacer sleeve
5
374813
Bracket
6
375000
Hydraulic valve
7
500019
Screw
8
904229
Washer 8,4x16x1,5
9
500033
Screw
10
904230
Washer 10,5x22x2
11
902287
Nut
12
334190
Connector
13
334135
T-connector
14
234481
Connector
15
234219
Connector
16
334116
Straight o-ring connector
17
482885
Hydraulic hose
18
482525
Hydraulic hose
19
482828
Hydraulic hose
20
483087
Hydraulic hose
20
482571
Hydraulic hose
21
813444
Elbow 90, O-ring
22
813500
Elbow 45, O-ring
23
483250
Hydraulic hose
24
483251
Hydraulic hose
25
373015
Clamp
26
334197
Elbow 90
27
234953
Connector
28
482889
Hydraulic hose
28
483109
Hydraulic hose
29
482588
Hydraulic hose
29
482728
Hydraulic hose
30
372424
Pilot valve
30
376109
Pilot valve
31
904229
Washer 8,4x16x1,5
32
373016
Hose clamp
