Каталог запасных частей к технике: DYNAPAC Dynapac CA302D. Cab Door (Cab Up to 68X20851)
1
1
1
2
2
2
3
4
5
6
7
8
9
10
11
12
13
14
15
15
15
16
16
16
17
18
19
20
21
21
21
22
23
24
25
25
25
26
27
28
29
29
29
30
31
31
31
31
32
32
32
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
57
57
57
57
58
59
60
61
62
63
64
64
64
65
66
67
68
69
70
71
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 938224 | Door cpl | |
| 1 | 936927 | Door cpl | |
| 2 | 938016 | Door frame | |
| 2 | 935254 | Door frame | |
| 3 | 935255 | List | |
| 4 | Rivet | Rivet | |
| 5 | 908987 | Seal | |
| 6 | 935256 | List | |
| 7 | 935257 | Ventilating grill | |
| 8 | 935258 | Panel plate | |
| 9 | 935259 | Screw | |
| 10 | 935260 | Panel | |
| 11 | 935261 | Panel | |
| 12 | 935262 | Support list | |
| 13 | Screw | Screw | |
| 14 | 935263 | Panel | |
| 15 | 935264 | Panel | |
| 15 | 938043 | Panel | |
| 16 | 909464 | Screen | |
| 16 | 937390 | Screen | |
| 17 | 908545 | Seal list | |
| 18 | 935265 | List | |
| 19 | Screw | Screw | |
| 20 | 935266 | List | |
| 21 | 909461 | Screen | |
| 21 | 937391 | Screen | |
| 22 | 908545 | Seal list | |
| 23 | 935267 | List | |
| 24 | 935268 | List | |
| 25 | 909462 | Screen | |
| 25 | 937392 | Screen | |
| 26 | 908545 | Seal list | |
| 27 | 935269 | List | |
| 28 | 935270 | List | |
| 29 | 909463 | Screen | |
| 29 | 937393 | Screen | |
| 30 | 908499 | Rubber list | |
| 31 | 935271 | Washer, Flexible | |
| 32 | 935272 | Washer, Black | |
| 33 | 935273 | Hinge | |
| 34 | 935274 | Screw | |
| 35 | 600006 | Washer | |
| 36 | 586003 | Lock nut M8 | |
| 37 | Screw | Screw | |
| 38 | Nut | Nut | |
| 39 | 935275 | Rubber washer | |
| 40 | 935276 | Bracket | |
| 41 | 936600 | Screw | |
| 42 | 936601 | Washer | |
| 43 | 936602 | Nut M5 | |
| 44 | 935277 | Lock pin | |
| 45 | Screw | Screw | |
| 46 | Washer | Washer | |
| 47 | Nut | Nut | |
| 48 | 935253 | Lock | |
| 49 | 935244 | Door handle with key | |
| 50 | 935245 | Seal | |
| 51 | 500012 | Screw | |
| 52 | 935246 | Seal | |
| 53 | 935247 | Leader | |
| 54 | 935248 | Turning mechanism | |
| 55 | 935249 | Retainer | |
| 56 | 935250 | Rod | |
| 57 | 935251 | Lock | |
| 57 | 938017 | Lock | |
| 57 | 902866 | Key Marked 455 | |
| 58 | 937890 | Screw | |
| 59 | 937891 | Screw | |
| 60 | 908580 | Lock pin | |
| 61 | 908581 | Washer | |
| 62 | 908582 | Cover | |
| 63 | 908583 | Bracket | |
| 64 | 935252 | Gas spring | |
| 64 | 938018 | Gas spring | |
| 65 | 937121 | Ball joint | |
| 66 | 600006 | Washer | |
| 67 | 586003 | Lock nut M8 | |
| 68 | 513025 | Screw | |
| 69 | 937056 | Hinge, cpl | |
| 70 | 937057 | Pin | |
| 71 | 938024 | Door stop |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
