Каталог запасных частей к технике: DYNAPAC Dynapac CA1500. Portplate with valves

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
1
2
3
4
5
6
7
8
9
10
10
11
12
13
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
28
29
30
31
32
33
98
Позиция на иллюстрации Заводской номер детали Название детали
1 4700937240 Pressure relief valve 440 bar
2 Lockingscrew Locking screw
3 Valvecollar Valve collar
4 Valvespindle Valve spindle
5 Springloadingnut Spring loading nut
6 Pressurespring Pressure spring
7 Threadedpin Threaded pin
8 4700927278 O-ring
9 4812157799 Back-up ring
10 4812158770 Locking set with orifice
11 Lockingscrew Locking screw
12 4700927278 O-ring
13 4812157797 Pressure override valve
14 Lockingscrew Locking screw
15 Valvebushing Valve bushing
16 Controlpiston Control piston
17 Piston Piston
18 Valvepiston Valve piston
19 Poppetseat Poppet seat
20 Pressurespring Pressure spring
21 Springcollar Spring collar
22 Adjustingscrew Adjusting screw
23 4700902783 O-ring
24 Sealingnut Sealing nut
25 Portplate Port plate
26 Socketheadscrew Socket head screw
27 Cylinderpin Cylinder pin
28 Doublebreak Double break-off plug
29 Lockingscrew Locking screw
30 Lockingscrew Locking screw
31 4700902641 O-ring
32 Lockingscrew Locking screw
33 4700901744 Plain roller bearing
98 4812157798 Seal kit, port plate with valves
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
