Hose assy kit for AC
Hose assy kit for AC
Compressor module
Belt guard module
Belt guard assy
Cooling box module
Lunch box
Strike off blade kit
Bearing mount
Hydraulic and Electrical, Strike off blade kit
4812121948 Hydraulic cylinder
Strike-off blade, mount
Indicator, module
Bracket, module
Locking device, module
FleetLink module
Compaction meter (DCM)
Dyn@lyzer
2
3
4
5
6
7
8
9
9
9
10
12
12
12
12
14
15
16
17
18
Позиция на иллюстрации
Заводской номер детали
Название детали
2
4812119093
Bracket
3
4700904230
Washer
4
4700500048
Hex. screw
5
4700287295
Clamp
6
4700904872
Cover plate
7
4700904229
Washer
8
4700500067
Screw
9
4700313041
Cable tie
10
4700792441
Cable tie with holder
12
4812117248
Cable tie with holder
14
4700792686
Cable tie with holder
15
4812119489
Refrigerant hose
16
4812119490
Refrigerant hose
17
4812113491
Refrigerant hose
18
4812113492
Refrigerant hose
